Tootegrupid
Profi köögisegisti pihusti otsik Delabie PEGU2.jpg Zoom

Delabie professionaalse köögisegistile pihusti-otsik 1/2" must

Tootekood: DE-433010
Kaubamärk:
Ühik: tk
Tarneaeg: 7-14 päeva
Hind:
165,00 €
Kuumakse alates: 14,03 €
Kogus: - +
   - või -

Delabie professionaalse köögisegistile pihusti-otsik 1/2" must

Black M1/2" hand spray

Ref. 433010

Black hand spray with adjustable jet and shock-resistant tip.
Scale-resistant diffuser (nozzle has no mesh).
Two jet options: rain effect - 8 lpm at 3 bar and concentrated jet - 9 lpm at 3 bar.
Reinforced polypropylene handle with non-slip grip (improved grip).
Chrome-plated solid brass.
Hand spray can be locked in open position using integrated collar.


TECHNICAL CHARACTERISTICS

Black M1/2" hand spray

Ref. 433010
Connector M1/2"
Height 168mm
Flow rate 8 - 9 lpm
Finish Polypropylene
Sarnased tooted
R/V teras veetrapp, D75 mm vertikaalne, 150x150mm
On võimalik versioonid , vertikaalsed, horisontaalsed D50mm,75mm,110mm





PV 01

stainless steel floor trap






PV 01 is a fully stainless floor trap with braz designed to drain showers, industrial premises and other inner spaces. The trap is designed as stepping (not driven-over). The trap is made of AISI 304 quality stainless steel. Detergents containing chlorine must not be used for cleaning. If chlorine is contained in the environment, we recommend custom-made model of another material (e.g. AISI 316).

For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).

We produce other custom-made models – outlet d = 50 mm, 110 mm; without rim for waterproofing; alternative cover grid (mesh); without braz; with adjustable height, etc. Send us your requirements, we will promptly answer!



Version types
PV 01.D.75.P - floor trap d = 75 mm, smell trap, outlet down, rim for waterproofing, not adjustable
PV 01.D.75.S - floor trap d = 75 mm, smell trap , outlet down , rim for waterproofing, adjustable
PV 01.B.75.P - floor trap d = 75 mm, smell trap , outlet to the side, rim for waterproofing, not adjustable
PV 01.B.75.S - floor trap d = 75 mm, smell trap , outlet to the side , rim for waterproofing , adjustable
PV 01.D.50.P - floor trap d = 50 mm, smell trap , outlet down , rim for waterproofing , not adjustable
PV 01.D.50.S - floor trap d = 50 mm, smell trap , outlet down , rim for waterproofing , adjustable
PV 01.B.50.P - floor trap d = 50 mm, smell trap , outlet to the side , rim for waterproofing , not adjustable
PV 01.B.50.S - - floor trap d = 50 mm, smell trap , outlet to the side , rim for waterproofing , adjustable
PV 01.D.110.P - floor trap d = 110 mm, smell trap , outlet down , rim for waterproofing , not adjustable
PV 01.D.110.S - floor trap d = 110 mm, smell trap , outlet down , rim for waterproofing , adjustable
PV 01.B.110.P - floor trap t d = 110 mm, smell trap , outlet to the side , rim for waterproofing , not adjustable
PV 01.B.110.S - floor trap d = 110 mm, smell trap , outlet to the side , rim for waterproofing , adjustable


Basic technical information
Minimum inner diameter: 70 mm
Diameter of connecting sewerage pipe: 75 mm
Water flow: min. 50 lts / min
Loading class: K3
Weight: 2,2 kg


Complete delivery
  • Trap body
  • Grid with braz cover
  • Hook to pull up the grid





Requirements for setting up the construction
  1. Completed sewerage drains terminated by DN 75 coupling
  2. Prepared hole in the floor with diameter min. 300 mm (200 mm without rim for waterproofing) and depth min. 120 mm

Tootekood: AZP-PV 01.D.75.P ,   Tarneaeg: 3-4 nädalad
423,00 €

Koristajavalamu R/V teras 455x330, pritsmisplekiga+ämberrestiga

Characteristics

  • stainless steel wall hung cleaner‘s sink
  • with splash-back and grating
  • overflow set
  • waste output Ø 50 mm
  • material CrNi 18/10 (AISI-304)
  • brushed finish
Order number 98010
Code SLVN 01



Характеристики

  • stainless steel wall hung cleaner‘s sink
  • with splash-back and grating
  • overflow set
  • waste output Ø 50 mm
  • material CrNi 18/10 (AISI-304)
  • brushed finish
Арт. № 98010
Название SLVN 01
Tootekood: SA-SLVN 01 ,   Tarneaeg: 3-4 nädalad
635,00 €

Jäik dushiots Presto, koos toruga 3/4" keermega

Tootekood: P29100 ,   Tarneaeg: 7-14 päeva
197,60 € (5%)
208,00 €

Deck-mounted single hole mixer - 45 lpm
Ref. 5640T2

Deck-mounted single hole mixer with swivelling, tubular spout Ø 22mm H. 195mm L. 200mm.
Star-shaped flow straightener.
Water-free, guided valve heads with reinforced mechanisms.
Shock-resistant, ergonomic ball levers.
Flow rate 45 lpm at 3 bar.
Full flow rate achieved within first 90°.
Spout with smooth interior.
Chrome-plated brass body and spout.
Reinforced fixing via two stainless steel rods.
F3/8" PEX flexibles.

Tootekood: DE-5640T2 ,   Tarneaeg: 7-14 päeva
409,00 €

Twin hole pre-rinse set with mixer
Ref. 5680

Complete pre-rinse set without bib tap.
Deck-mounted twin hole mixer with 150mm centres with:
- Valve heads with reinforced mechanisms with ergonomic control levers.
- Offset inlet connections with M1/2" tails.
Black, scale-resistant M1/2" hand spray with adjustable jet and 9 lpm flow rate at the outlet.
Black, reinforced, food-grade flexible hose L. 0.95m.
3/4" brass column.
Adjustable wall bracket.
Stainless steel spring guide.

TECHNICAL FEATURES

Twin hole pre-rinse set with mixer
Ref. 5680

Connector M1/2"
Height 1110 - 1230mm
Drop height 345 - 585mm
Flow rate 9 lpm
Width to the wall 35 - 162mm
Finish Chrome-plated brass
Tootekood: DE-5680 ,   Tarneaeg: 14-21 päeva
1079,00 €
Projektide hinnapäringud ja tooteinfo kättesaadavusega seotud küsimused palume saata e-mailile info@pegu.ee
