Normbau Inox Care Lift-up inva käepide ülestüstetav 2050050 vario, suspendable, L = 850mm, siena kinnitusega

Inox Care Lift-up support rail 2050050 vario, suspendable, L = 850mm, with base plate

Lift up support rail vario with base plate,
length 850mm, 32mm dia.,

made of stainless steel, material No. 1.4301 (A2 AISI 304), brushed finish, left or right hand application, space required in vertical position 193mm from wall, with adjustable brake, easy installation by mounting to a base plate.
Base plate, made of stainless steel for balanced wall mounting, concealed screw fixing, supplied without fixing screws and plugs, conform to German standard DIN 18040 1-2, maximum loading permitted: 125 kgs.
850mm length conform to German standard DIN 18040-1/2, Austrian standard ÖNORM B1600.

TÜV PRODUKT SERVICE certified.

Select appropriate fixing material to suit site conditions. Can be fitted with paper roll holder 2050 300 may be added at a later stage.

General Description

 Toilet paper dispenser for two standard rolls, surface mounted.  Suitable design for easy integration in the washroom and compatible with the line of washroom accessories Mediclinics®.

 Manual dispensing.

 One-piece body.  Suitable for high traffic facilities and for public use.  High strength, durability and anti vandalism model. Components & materials

 PR2784: steel, white Epoxy finish.

 PR2784C: stainless steel AISI 304, bright finish.

 PR2784CS: stainless steel AISI 304, satin finish.

 PR2784B: steel, black Epoxy finish.

 One-piece body, 0.8 mm thick with burr-free edges.

 One-piece lid, 0.8 mm thick, weld-free, fixed to the body by means of two rivets that allows swinging down of the lid for the replenishment.

 Back-plate 0.8 mm thick with slots for easy installation.

 Two slots in both sides that indicates the content level.

 Plastic holder for spare roll can be regulated in two different positions, depending on the size of the paper roll and allowing free movement of the roll in use. The toilet paper descends when the previous one has been finished by simply putting the hand through the side slot.

 Lock with standard Mediclinics® key
