Normbau Inox Care Lift-up inva käepide ülestüstetav 2050050 vario, suspendable, L = 850mm, siena kinnitusega

Inox Care Lift-up support rail 2050050 vario, suspendable, L = 850mm, with base plate

Lift up support rail vario with base plate,
length 850mm, 32mm dia.,

made of stainless steel, material No. 1.4301 (A2 AISI 304), brushed finish, left or right hand application, space required in vertical position 193mm from wall, with adjustable brake, easy installation by mounting to a base plate.
Base plate, made of stainless steel for balanced wall mounting, concealed screw fixing, supplied without fixing screws and plugs, conform to German standard DIN 18040 1-2, maximum loading permitted: 125 kgs.
850mm length conform to German standard DIN 18040-1/2, Austrian standard ÖNORM B1600.

TÜV PRODUKT SERVICE certified.

Select appropriate fixing material to suit site conditions. Can be fitted with paper roll holder 2050 300 may be added at a later stage.

45 series electronic basin mixer with infrared sensor. Battery operated

148 x 448 x 120 mm
950 ml tank

• Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
• One-hand operated and non-drip disinfectant pump with 950 ml tank.
• Tank with large, lockable refill opening.
• Designed for standard disinfectants.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, removable front panel with fall protection.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts and front panel can be replaced as modules.
• Installation dimensions: 150 x 450 x 110 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and first fill with soap.

• Weight (in kg): 3,0

Ukse lukukate 6mm (sisemine) D Line FAT AISI 316 Ø70mm roostevaba teras

Ø70 mm (2,7")

Height: 6 mm (0,2")

Center - center distance (between screw fixings): 38/27 mm (1,5"/1")

Together with British designer Tom Dixon we’ve created FAT, a new line of hardware pieces.

Our Ø70mm Fat escutcheon w/PZ hole for the inside of an exterior door (ie. a front door),  is enduringly crafted in the highly resilient AISI 316 stainless steel preferred by d line and enhanced by a 20-year product guarantee.

The Fat collection comprises a lever handle, key escutcheon and thumb turn, as well as a door knocker, pull handle, flush pull and door stop. Like the rest of the d line portfolio, each piece is minimalist enough to be timeless in its design, its beauty coming from its rounded profile and inflated silhouette, rather than from superfluous details.

Tom Dixon uses the word ‘fat’ to imply generosity and softness of form. The result lacks any trace of sharpness or angularity and is a collection of pumped-up pieces that are simply ‘fatter’ than the norm.

The collection is available in charcoal, electric blue, polished brass and our signature satin stainless steel.

To achieve the collection’s aesthetic, Tom Dixon has magnified the silhouette of each piece’s ‘normal’ aesthetic. That’s why the diameter of our Fat lever roses and escutcheons are Ø70mm. This means, that our Fat lever handle, escutcheons and thumb turns will match lock cases where the backset minus the rebate is a minimum of 40mm. The center distance between the lever handle and escutcheon/thumb turn should also be a minimum of 71mm. For further information, please contact us.
