Water inlet | G 1/2" |
Water pressure | 0,2 – 0,6 MPa (recommended 0,3 MPa) |
Outlet | d = 40 mm |
Inner dimension of the fountain | d = 245 mm |
Weight | 4 kg |
Müüja: PEGU OÜ
Olete leidnud õige toote – nüüd on aeg see enda omaks teha.
Lisage toode ostukorvi ja jätkake tellimusega – nii on ta varsti juba teie juures!
PEGU.ee – targad valikud inimestele, kes hindavad stiili ja kvaliteeti.
jöögifontöön
pudelitäitmisekraaniga
Liivapüüdur SAND-02 Elcee 220, 3,5L, R/V teras, AISI304
Kasutusjuhend:
Liivapüüdur SAND-02 Elcee 220, 3,5L, roostevaba teras, AISI304
Liivapüüdur SAND-02 Elcee 220 on mõeldud liiva filtreerimiseks veest ning selle maht on 3,5 liitrit. Seade on valmistatud roostevabast terasest (AISI304) ja on ideaalne paigaldamiseks otse kraanikausi või valamualuse alla.
Paigaldamine:
Liivapüüdur on lihtne paigaldada otse kraanikausi või valamualuse alla, kasutades selleks sobivaid kinnitusvahendeid.
Kasutamine:
Liiv ja mustus kogunevad seadme alumisse kaussi. Seadme efektiivse töö tagamiseks on vajalik kaussi regulaarselt tühjendada.
Hooldus:
Kauss on kinnitatud korpuse külge kahest küljest kinnitustega. Kaussi puhastamiseks eemaldage see kinnitustest, tühjendage ja vajadusel puhastage.
Üldmõõtmed millimeetrites: Ø174 x 235
Sissevoolu mõõtmed millimeetrites: 1,5"
Väljavoolu mõõtmed millimeetrites: 1,5"
Materjal: AISI 304
Materjali paksus millimeetrites: 1,5
Kogukaal kilogrammides: 2,50
Wash trough acc. Separator SAND-02
Description
The sand catcher has a capacity of 3,5 litres and is ideal for filtering sand from water.
It is easy to mount directly under a washbasin or a wash trough.
The sand catcher is delivered with a flexible outlet that will enable straight or bent installation possibilities.
Material: Stainless steel AISI 304
Overall dimension in mm Ø174 x 235
Inlet dimension in mm 1.5"
Outlet dimension in mm 1.5"
Material AISI 304
Material thickness in mm 1.5
Gross weight in kg 2.50
AFO 01 is a stainless steel wall-mounted drinking fountain of modern design with a manual press valve that allows its easy use. The water flows only when the valve is pressed and then there is a certain adjusted time to rinse out the nozzle.
The water inlet is fitted with a flexible hose, the siphon is made from a stretchy, flexible connector. The flexible finish of the water inlet and outlet allows the variable and problem-free connection of the fountain.
AFO 01 stainless steel fountain is suitable mainly for schools, medical facilities and spa resorts, and is utilizable outdoors.
AFO 01 is made of stainless steel AISI 304.
AFO 01.CL is made of stainless steel AISI 316 and is suitable into the areas with higher concentration of chlorine (e.g. swimming pools).
Sensor-controlled fountain possible made to order.
For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).
Water inlet | G 1/2" |
Water pressure | 0,2 – 0,6 MPa (recommended 0,3 MPa) |
Outlet | d = 40 mm |
Inner dimension of the fountain | d = 245 mm |
Weight | 4 kg |
AFO 01.Y is st. stainless wall hung drinking fountain controlled by sensor. Water runs after disrupting the scanning zone.
Fountain is made by welding all components together.
Fountain is suppplied with safety power 12 V, 50 Hz from power supply ZAC (AFO 01.Y) or with 4x AA battery (AFO 01.YB).
Material is standardly st. steel AISI 304 or can be AISI 316 (AFO 01.Y.CL or AFO 01.YB.CL).
St. steel driking fountain AFO 01.Y is based on favourite model AFO 01 with manual control.
The sensor, located on the right side of the fountain, is reacting on the approach of the user. Water starts to run from the nozzle, located in the middle of the fountain bowl, and runs over the time when the user´s head is in the scanning zone (max. 30 sec.) + preset time (max. 4 sec.) to clean the nozzle.
water inlet | G 1/2" |
water pressure | 1 - 10 Bar (AFO 01.Y; AFO 01.Y.CL) |
2 - 8 Bar (AFO 01.YB; AFO 01.YB.CL) | |
outlet | d = 40 mm |
bowl inner dimension | d = 245 mm |
weigth | 4 kg |
suppply | 12 V, 50 Hz (AFO 01.Y; AFO 01.Y.CL) |
6 V - 4 x AA battery (AFO 01.YB; AFO 01.YB.CL) | |
power supply | ZAC 1/20 (max. 3 x AFO 01.Y ; AFO 01.Y.CL) |
AFO 04 is a stainless-steel drinking fountain of a modern design. It is manufactured with a double surface finish: matt bowl (blasted with ballotini) and brushed casing. Thanks to its interesting appearance, it particularly suits public spaces, such as sports facilities, parks, squares, business centres, fitness and wellness centres, but also schools and kindergartens.
Similarly to AFO 01, the drinking fountain is operated with a push valve. Water is flowing while the valve is pushed and for a preset time after its release, in which way the nozzle is rinsed.
The water inlet is through a flexible hose; siphon trap is made of a flexible coupling. The flexible design of the water inlet and outlet enables variable and trouble-free connection of the fountain as well as its simple dismounting.
The AFO 04 drinking fountain is made from stainless steel of the AISI 304 class; the AFO 04.CL drinking fountain is made from steel of the AISI 316 class.
Package contents
Water inlet | G 1/2" |
Water pressure | 2 - 6 Bar (recommended 3 Bar) |
Outlet | d = 40 mm |
Inner dimension of the fountain | d = 245 mm |
Weight | 4 kg |
