450 x 450 x 130 mm
400 ml foam soap concentrate / ca. 500 paper towels

• Mirror cupboard with integrated foam soap dispenser and paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; visible surfaces satin finished and brushed.
• Crystal mirror with all round 2 mm chamfer and frosted window for optional lighting set.
• Foam soap dispenser with one-hand operated and non-drip foam soap pump.
• Designed for standard 400 ml foam soap concentrate.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 500 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
• Accessible for refilling through lockable door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Lighting set available as an option.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, first fill with foam soap concentrate and one pack of paper towels.

• Weight (in kg): 11,0

• Hardened steel anti-corrosion
• powder coated steel UV
• Front embossed deterring wild display and tags
• System discreet keyless entry (inside latch)
• Accessories: Inner tray galvanized steel 30L ref. 59351
Dimensions: 405X238X605
Weight of the basket: 12.165 kg

• WASTE DEPOSIT FLAP WP 154-1

  300 x 235 x 30 mm

  • Self-closing, flame-retardant waste deposit flap in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel construction; visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • No wearing parts, smooth closing by counterweight.
  • Mounting: Insert and glue into cutout.
  • Installation dimensions: 277 x 210 mm
  • Weight (in kg): 1,5

  AVAILABLE SURFACES	ORDER NUMBERS
  satin finished (standard)	727230
  highly polished	731230
  (coloured) plastic powder - coating	728230
