> THE PRODUCT BENEFITS

Resistant to intensive use
Reinforced body / spout interface with double sliding bearings: no play and high endurance
Robust spout: 22 mm in diameter
Intuitive and ergonomic knobs: easy grip
Hygiene: spout with smooth interior
Product design
Ease of cleaning
High spout to let large containers pass
Easy maintenance: presence of a slot under the red / blue patch allowing the passage of a screwdriver Ease of maintenance: availability of all spare parts
Flow straightener to channel water and avoid lateral water splashes

> TECHNICAL SPECIFICATIONS > Model:

Deck-mounted single hole mixer with upward spout
360 ° swivel spout, projection 250 mm, height under spout 251 mm, diameter 22 mm. Spout thickness: 1.5 mm. 1/4 turn ceramic head with flow rate 37L / min at 3 bar
Interchangeable anti-tartar flow straightener

> Recommended working pressure:

1 to 5 bars

> Flow rate:

37L / min at 3 bar

> Hydraulic supply:

G 1/2 '' (15x 21)

> Material and color of finish:

Chromed brass body and spout Material compliant with the "UBA" list

> Thermal resistance :

Withstands a temperature of 75 ° C for 30 minutes (as part of thermal shock).

> Delivered with:

1 fixing bracket
2 PEX flexible hoses with stainless steel braided nut G1 / 2 '' Lg 660 mm with non-return valves NF 2 filters

> Option:

Possibility of adding an extension sold separately, facilitating the passage of large containers

> Standards and approvals:

Chromed brass body compliant with standards NF EN1982 / NF EN 12164 / NF EN 12165 Nickel-Chrome surface treatment according to NF EN12540
Resistance to neutral salt spray (NSS): 200 h according to NF ISO 9227
