LVI disain roostevaba kaas 197x197x4 TÄHKÄ

Vieser 51208 Tõsterõngas külgavadega 3x32 mm

Vieser extension ring with side inlets 3x32mm

HVAC No. 3318452

Compatible with all Vieser floor drains. Installed below the waterproofing.

Raises the floor drain by 66–91 mm.

Three 32-mm side inlets can be connected to the extension ring.

The package contains the extension ring, a grey lip seal and a white clamping ring.

Technical specifications

Vieser No.

51208

HVAC No.

3318452

EAN

6418685512086

Package (box/pallet)

22/176

Package dimensions

20 x 10 x 20 cm

Package weight

0,3 kg

Material

Polypropylene PP

Usage

To be installed into Vieser floor drains below the waterproofing. Three 32-mm side inlets can be connected to the extension ring.

General information

An extension ring that raises the floor drain by 66-91mm. The package contains the extension ring, a grey lip seal and a white clamping ring.

Tootekood: AKV51208 , Tarneaeg: 3-7 päeva

18,30 €

Trapikaas reguleeritava terasraamiga 51292 Vieser Classic+ 197x197 mm RST

Trapikaas reguleeritava terasraamiga AKV51292 Vieser Classic+ 197x197 mm

Roostevaba teras

Vieser Classic+ with adjustable steel frame 197×197

HVAC No. 3315955

NEW! AVAILABLE IN JUNE.
Floor drain grating made of durable, Finnish stainless steel.
A timeless and elegant redesign.

Type approved based on European standard
(EN 1253) – Withstands up to 300 kg, excellent flow properties
Strong and pleasant underfoot – remains firmly in place
Manufactured in Finland
Compatible with all Vieser floor drains
Adjustable steel frame – easy to install

The package includes the Vieser stainless steel Classic+ square grating and adjustable steel frame. To facilitate the installation of the tiling, the frame can be adjusted by a maximum of 15 mm off-centre of the floor drain, for a total adjustment range of 30 mm.

Vieser’s drain and grating combination comes with a 10-year system guarantee.

Download a tiling example:

(PDF) Tiling example for Vieser round and square gratings

(DWG) Tiling example for Vieser round and square gratings

Technical specifications

Vieser No.

51292

HVAC No.

3315955

EAN

6418685512925

Package (box/pallet)

20/480

Package weight

0,6

Material

Stainless steel (AISI 304)

Durability

300 kg

Tootekood: AKV51292 , Tarneaeg: 3-7 päeva

73,20 €

Trapikaas plastraamiga 51254 Vieser Classic 160x160 mm RST

Trapikaas plastraamiga 51254 Vieser Classic 160x160 mm

Roostevaba teras

Vieser Classic - Stainless steel grating with plastic frame – 160×160

HVAC No. 3316255

For tiled floors on top of the floor drain. Must be installed when tiling the floor. The gap between the floor drain and the square grating may not be sealed.

The package contains a square stainless steel grating and a plastic frame.

Vieser’s drain and cover combination comes with a 10-year system guarantee.

Our stainless steel gratings are fully compatible with
all our drains and extension rings.

(PDF)Vieser round and square grating in tiled floor

(DWG)Vieser round and square grating in tiled floor

Technical specifications

Vieser No.

51254

HVAC No.

3316255

EAN

6418685512543

Package (box/pallet)

20/800

Package dimensions

22 x 2 x 18,5 cm

Package weight

0,4kg

Material

Grating: Stainless steel (AISI 304) Frame: ABS

Durability

200kg

Usage

For tiled floors on top of the floor drain. Must be installed when tiling the floor. The gap between the floor drain and the square grating may not be sealed.

General information

The package contains a square stainless steel grating and a plastic frame.

Our stainless steel gratings are fully compatible with
all our drains and extension rings.

Tootekood: AKV51254 , Tarneaeg: 3-7 päeva

51,85 €

Vieser reguleeritav terasraam 51280 197x197 mm RST

Roostevaba teras

Vieser adjustable stainless steel frame 197 x 197

HVAC No. 3316229

Adjustable stainless steel frame 197×197 mm
Suitable for use with all Vieser 197×197 mm stainless steel gratings
To make tilework installation easier, the frame can be adjusted max 15 mm toeach direction. The complete adjustment range is 30 mm
Professional’s choice

Vieser’s drain and cover combination comes with a 10-year system guarantee.

(PDF)Vieser round and square grating in tiled floor

(DWG)Vieser round and square grating in tiled floor

Technical specifications

Vieser No.

51280

HVAC No.

3316229

EAN

6418685512802

Package (box/pallet)

15/600

Package dimensions

22,5 x 1,5 x 22 cm

Package weight

0,165 kg

Material

Stainless steel (AISI 304)

Usage

To facilitate the installation of the tiling, the frame can be adjusted by a maximum of 15 mm in any direction. The total adjustment range is 30 mm.

General information

The package contains an adjustable steel frame. To facilitate the installation of the tiling, the frame can be adjusted by a maximum of 15 mm in any direction.

Tootekood: AKV51280 , Tarneaeg: 3-7 päeva

36,60 €

Vieser nurgatrapikaas 6005080 Corner Modern 376 x 376 x 526 RST

Roostavaba teras

Vieser Corner Modern triangular floor drain 376 x 376 x 526

HVAC No. 3317311

An elegant triangular floor drain grating designed and manufactured in Finland, Vieser Corner Modern adds a personal touch and a polished look to your bathroom.

The Vieser floor drain is sold separately.

Choose the Vieser floor drain that is right for your Vieser Corner floor drain system

Compatibility with all Vieser One floor drains means that you can choose either a vertical, horizontal or untrapped floor drain, thereby also guaranteeing quick and easy installation.
Suitable for both new construction and renovations.
To facilitate the installation of the tiling, the frame can be adjusted by a maximum of 15 mm off-centre of the floor drain. The total adjustment range is 30 mm.
The package contains: A triangular, stainless steel Vieser Corner grating, an adjustable steel frame and an easy-to-use installation template.
The watertightness and proper functioning of the floor drain have been proven in rigorous tests conducted according to the standard EN 1253-2, on which the Vieser One floor drain type approvals are also based. (Vieser One floor drain type approval)
The compatibility and watertightness of Vieser One floor drains and the liquid-applied waterproofing of wet spaces have been proven in tests conducted according to the standard EN 1253-1, on which Vieser’s product certificates are also based. (Vieser One and Vieser product certificate).
Compatibility with Vieser One floor drains offers the user an easy-to-remove water trap that is easy to clean and reinstall.

Vieser’s drain and cover combination comes with a 10-year system guarantee.

(PDF)Vieser Corner floor drain system - Tiling example

(DWG)Vieser Corner floor drain system - Tiling example

Technical specifications

Vieser No.

6005080

HVAC No.

3317311

EAN

6430066742790

Package (box/pallet)

12/144

Package dimensions

410 x 410 x 580

Package weight

1,2 kg

Material

Stainless steel (AISI 304)

Durability

200kg

Usage

For tiled floors on top of the floor drain. Installation takes place when the floor is being tiled. The gap between the floor drain and the triangular grating must not be sealed.

General information

The package contains: A triangular, stainless steel Vieser Corner grating, an adjustable steel frame and an installation template.

To facilitate the installation of the tiling, the frame can be adjusted by a maximum of 15 mm off-centre of the floor drain. The total adjustment range is 30 mm.

The Vieser floor drain is sold separately.

Choose the Vieser floor drain that is right for your Vieser Corner floor drain system

Tootekood: AKV6005080 , Tarneaeg: 3-7 päeva

303,98 €
