General description

•   Wall-floor grab bar, with three support points, made of a diameter of 32 mm AISI 304 stainless steel tube, bent in an "L" shape at 90o and with a 32mm diameter lateral arm, welded on the lower part of the grab bar and also bent at 90°.

•   With snap flange covers that conceal the installation screws, improving the aesthetics of the bars once installed on the wall.

•   These grab bars offer a great safety and comfort to the user, helping to make the bathroom much safer for the elderly or those with reduced

  mobility. Models suitable for public use.

•   Well suited for keeping bathrooms and public enclosures barrier-free.

•   Highest durability and great resistance to rusting.

•   Optionally, these grab bars can be electrically isolated, installing the electrical isolation kit code KA0020.

•   Supplied with plugs and screws to fix the bar to a brick wall.

  Components and materials

  •   BSD020C: right hand grab bar made of AISI 304 stainless steel tube, bright finish.

  •   BSI020C: left hand grab bar made of AISI 304 stainless steel tube, bright finish.

  •   BSD020CS: right hand grab bar made of AISI 304 stainless steel tube, satin finish.

  •   BSI020CS: left hand grab bar made of AISI 304 stainless steel tube, satin finish.

  •   TUBING: made of a 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter along the bends.

  •   CONCEALED MOUNTING FLANGE: three units made of AISI 304 stainless steel, 3 mm thick. Incorporates two Ø 6.5 mm screw holes for wall mounting.

  •   SNAP FLANGE COVER: three units made of AISI 304 stainless steel, 0.8 mm thick and Ø 82 mm. Each cover snaps over mounting flange to conceal mounting screws.

General description

•   White epoxy-coated grab bars curved in 90o, to be installed on the wall, with Polypropylene snap flanges and made of Ø 32 mm steel tube.

•   These grab bar make the daily life-management of not only the disabled and elderly people easier but also it is a great support for everybody who needs help with moving.

•   Especially designed to achieve barrier-free accessibility in bathrooms and public spaces.

•   With three snap flanges, made of white Polypropylene that provide a clean finished look hiding the mounting screws.

•   Easy to clean.

•   Optionally, they have a kit to avoid electrical conductivity (code KA0010).

•   Fixing screws for brick wall included.

  Components and materials

•   BAD090C & BAI090C: right hand grab bar made of steel, white finish.

•   BAD090CS & BAI090CS: left hand grab bar made of steel, white finish.

•   TUBING: made of 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter

  along the bends.

•   CONCEALED MOUNTING FLANGE: three units made of steel, 3 mm thick. Incorporates two Ø 6.5 mm screws holes for wall

  mounting.

•   SNAP FLANGE COVER: three units made of Polypropylene, 1.5 mm thick and Ø 85 mm. Each cover snaps over mounting flange
