148 x 448 x 120 mm
950 ml bottle

• Sensor liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
• With EWAR® eModule touch-free operated soap pump.
• Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
• Also refillable with large container using the plug-in tank as an option.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, removable front panel with fall protection.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts and front panel can be replaced as modules.
• Installation dimensions: 150 x 450 x 110 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material, batteries and first fill with soap.

• Weight (in kg): 4,4

400 x 600 x 200 mm
ca. 48 l

• Waste basket in robust, germ-reducing and easy-care stainless steel wire (AISI 304).
• 2.5 mm and 4 mm thick lattice work. Fastening eyes in second row for invisible wall mounting.
• Capacity approx. 48 l.
• Mounting: With two screws.
• Delivery includes fixing material.

• Weight (in kg): 1,1

korpus

äravool

ilukate
