Range: SO'O

Ref: 56196 - Deck-mounted mixer sensor tap - Battery - Black and pink gold cover

Powered by TCPDF (www.tcpdf.org)

> Working pressure :

1 to 5 bar

> Flow :

3 l/min with integrated flow regulator High quality anti-limescale aerator Anti-water-hammering design

> Hydraulic supply :

G 3/8" (12x17)

> Power supply :

6 V lithium battery (CRP2 type) in a casing placed within the tap body

> Material and colour finish :

Chrome-plated metal alloy components Injected molded metal body and cover Black finish with pink gold cover

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Temperature limited by adjustable stop
Anti-overflow security time: 30 seconds
Anti-blocking system preventing the water to flow continuously
Solenoid valve automatically shut down in case of power shortage or in case of sensor degradation

> Delivered with:

2 Fastening nuts
1 Gasket and 1 Washer
2 PEX flexible hoses with F 3/8'' nut (12x17) and NF non-return valve 2 Straight stop valves G 3/8" (12x17)
2 Filter gaskets
Instructions manual

> Standards & approvals :

200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227

> Working pressure :

2 to 5 bar

> Flow :

1.9 l/min with integrated spray flow regulator High quality anti-limescale aerator Anti-water-hammering design

> Flow time:

7 sec adjustable with PRESTOCOM : http://www.presto.fr/whatabout/prestocom/ Sensor trigger suitable for elderly and disabled people

> Hydraulic supply :

G 1/2" (15x21) - Cold or premixed water

> Power supply :

Integrated 9V lithium battery

> Material and colour finish :

Brass body Chrome finishing

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Automatic shutdown of solenoid valve in case of power failure or sensor error Duty flush 30 sec each 24h after last use (adjustable flow time and frequency) Low battery alert (blinking led light)

> Delivered with :

1 Brass clamping nut
1 Gasket and 1 Washer 1 Filter gasket
1 Self-adhesive sticker Instruction manual

> Standards & approvals :

Brass body in accordance with NF EN1982, EN12164, NF EN 12165, UBA list compliant 200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227
ACS
