32 x 32 x 111 mm
projection 87 mm

• Tabletop soap dispenser, lockable, in chrome-plated brass.
• Solid body in brass; visible surfaces high-gloss chrome-plated.
• Design height: 111 mm
  Outlet height: 62 mm
  Projection: 66 mm
• Non-drip soap pump with 500 ml soap container in plastics and pressure valve in brass.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard liquid soaps.
• Refillable from above by unscrewing the top part, secured with hexagon socket screw.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 1,0

80 x 298 x 120 mm
950 ml tank

• Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing with rounded vertical corners. Visible surfaces satin finished and brushed. Further available surfaces: see below.
• One-hand operated disinfectant pump with 950 ml tank.
• Tank with large, lockable refill opening.
• Designed for standard disinfectants for hands.
• Note: Not approved for medical areas.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 1,1

350 x 448 x 210 mm
1 paper roll

• Sensor paper roll dispenser, mains-operated, in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom.
  Further available surfaces: see below.
• With touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm. Paper length and idle time adjustable.
  Mains-operated 230 V / 50 Hz; power rating 7 Watt; mains cable on site. TÜV/GS-tested and certified.
• Designed for one paper roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
• Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
• Accessible for refilling through lockable door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 352 x 450 x 180 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and first fill with one paper roll.

• Weight (in kg): 10,3
