80 x 298 x 120 mm
400 ml foam soap concentrate

• Foam soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• One-hand operated and non-drip foam soap pump.
• Designed for standard 400 ml foam soap concentrate.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With two screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material and first fill with foam soap concentrate.

• Weight (in kg): 2,4

148 x 148 x 50 mm
for 1 sanitary bag box

• Sanitary bag dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304.
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Designed for one standard sanitary bag box with dimensions of approx. 118 x 87 x 20 mm.
• Accessible for refilling through lockable front flap.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Installation dimensions: 150 x 150 x 40 mm.
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and first fill.

• Weight (in kg): 0,8

Ø 30 x 86 mm
projection 90 mm

• Tabletop disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished. Further available surfaces: see below.
• Design height:86 mm
  Outlet height: 68 mm
  Projection: 76 mm
• Non-drip disinfectant pump with 500 ml disinfectant bottle in plastics and pressure valve in stainless steel.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard disinfectants.
• Refillable from above by unscrewing the top part.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,7

Tööpinda läbiv raam, R/V teras

AISI 304, harjatud

298 x 148 x 20 mm

• Waste disposal frame in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel construction; visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Mounting: Insert and glue into cutout.
• Installation dimensions: 258 x 110 mm

• Weight (in kg): 0,5

326 x 173 x 164 mm
ca. 250 paper towels

• Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• With deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag- or c-fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Accessible for refilling through lockable front flap.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Installation dimensions: 300 x 150 mm
• Mounting: With four screws on the inside, sideways.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 3,4
