ELECTRONIC TOUCH-FREE PAPER ROLL DISPENSER BATTERY POWERED WP 1311
350 x 448 x 210 mm 1 paper roll
Choose product variant
Sensor paper roll dispenser, battery-powered, in robust, germ-reducing and easy-care stainless steel (AISI 304).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom. Further available surfaces: see below.
With touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm. Paper length and idle time adjustable. Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries.
Designed for one paper roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
Accessible for refilling through lockable door.
Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
Wear parts and front panels can be replaced as modules.
Installation dimensions: 352 x 450 x 180 mm
Mounting: With four screws in wall opening through fixing holes in the side walls.
Delivery includes fixing material and first fill with one paper roll.
Weight (in kg): 10,3
AVAILABLE SURFACES
ORDER NUMBERS
satin finished (standard)
733240
highly polished
731240
(coloured) plastic powder - coating
728240
Suggested text for specifications:
Sensor paper roll dispenser, battery-powered, in stainless steel (AISI 304) for flush mounting. All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom. With touch-free operated, capacitive sensor technology. Paper length and idle time adjustable. Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries. Designed for one paper roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm. Inspection slot to indicate fill level. Accessible for refilling through lockable door. Residual roll function allows a reserve roll to be inserted before residual roll is completely used up. Keyed alike cylinder lock in corrosion-resistant zinc die-casting. Delivery includes fixing material and first fill with one paper roll.
- Anti-UV powder coated steel - Antivandalism: lock with triangular latch lock - Anti-corrosion polypropylene skids avoiding contact with the ground - 2 adjustable plastic feet for uneven floors - Sort type identification: color plate with calibrated aperture - Signage on the door - Recommended installation in a covered area - Bag 130L - Size: 580x1180x590 - Color: Paper - Manganese Gray / Sky Blue RAL 5015
COMBINATION PAPER TOWEL-, SENSOR - SOAP DISPENSER 950ML BOTTLE AND WASTE BIN WP 500E
298 x 1348 x 120 mm ca. 250 paper towels / sensor with 950 ml soap bottle / 11 l
Combination consisting of a sensor liquid soap dispenser, paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
Also refillable with large container using the plug-in tank as an option.
Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
Designed for approx. 250 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
Inspection slots to indicate fill level.
Accessible for refilling through lockable front flap with fall protection.
Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
eModule battery-powered with two 1.5 V Baby/LR14 batteries. Power supply available as an option.
Wear parts and front panels can be replaced as modules.
Installation dimensions: 300 x 1350 x 110 mm
Mounting: With eight screws in wall opening through fixing holes in the side walls.
Delivery includes fixing material, batteries, first fill with soap and one pack of paper towels.
