50 x 172 x 161 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid rectangular stainless steel body; visible surfaces satin finished. Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M24 x 1 mm.
• Design height: 172 mm
  Outlet height: 92 mm
  Projection: 97 mm
  Length of lever: 65 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 2,3

148 x 448 x 120 mm
950 ml tank

• Sensor disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
• With EWAR® eModule touch-free operated disinfectant pump with 950 ml tank.
• Tank with large, lockable refill opning.
• Designed for standard disinfectants.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, removable front panel with fall protection.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts and front panel can be replaced as modules.
• Installation dimensions: 150 x 450 x 110 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and batteries.

• Weight (in kg): 3,4

Süvistatud dušisüsteem Damixa SILHOUET HS1 steel PVD

Tähelepanu! Seinasisene dušisüsteem on ilma seinasisese tööelemendita.
