380 x 1350 x 380 mm
950 ml tank

• Hygiene station consisting of a sensor-disinfectant dispenser and a floor-stand in robust, germ-reducing and easy-care stainless steel.
• Visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor-disinfectant dispenser in stainless steel (AISI316L) with rounded vertical corners.
  • With EWAR® eModule touch-free operated disinfectant pump with 950 ml tank.
  • Designed for standard disinfectants.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable, hinged housing.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  • Wear parts can be replaced as modules.
  • Delivery includes batteries.
• Floor-stand in stainless steel (AISI304)
  • Base plate with rubber feet.
  • Intended for free floor installation.

• Weight (in kg): 10,1

> Working pressure: 1 to 5 bar

> Flow: 3 l/min at 3 bars - 4-position setting Anti water-hammer system

> Flow time: 15 seconds - lever upwards or downwards

> Hydraulic supply: 2 PEX hoses DN8 G3/8'' - 350mm

> Thermal resistance: This tap can withstand a thermal shock of 75°C for 30 minutes as part of a thermal shock programme

> Safety: With temperature limiter (at 38°C for cold water at 15°C/3 bar and hot water at 60°C/3 bar)

> Convenience: Soft-touch Two-coloured ergonomic lever, in glass fiber reinforced polymer

> Delivered with: 2 PEX hoses with swivel nut and NF check valves 1 base gasket 2 MM 3/8'' (12x17) stop valves 2 Filter gaskets 1 Fixing bracket > Standards / Approvals: Chrome-plated brass body compliant with standards NF EN1982 / NF EN12164 / NF EN12165 Nickel-Chrome surface treatment compliant with NF EN12540 Neutral Salt Spray (NSS) resistant: 200 h according to NF ISO 9227

Elektrooniline seinasisene valamukraan külma/eelsegatud veele Roostevaba teras AISI316L  6V, ON/OFF

Elektrooniline seinasisene valamukraan külma/eelsegatud veele AISI316L  6V, ON/OFF

Roostevabast terasest AISI316L

• Visible parts in brushed stainless steel
• Bi-stable solenoid valve 6V (internal)
• Infra-red sensor
• 6V CRP2 lithium battery (external)
• Chassis for mural installation or plasterboard walls
• Adjustable built-in position from 0 to 30mm
• Infrared sensor with ON/OFF mode
• Automatic anti-stagnationella water flow every 24h after last use
• Self-closing after 60 seconds of continuous flow
