Seebidosaator kontaktivaba SoapTap DAN DRYER 378

Damixa seebidosaator 75mm otsik, kroom

480000

75 mm otsik

298 x 1348 x 120 mm
ca. 250 paper towels / 400 ml foam soap concentrate / 11 l

• Combination consisting of a foam soap dispenser, a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Foam soap dispenser with one-hand operated and non-drip foam soap pump.
• Designed for standard 400 ml foam soap concentrate.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 300 x 1350 x 110 mm
• Mounting: With eight screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material, first fill with soap and one pack of paper towels.

• Weight (in kg): 14,9

93 x 290 x 225 mm
1000 ml bottle

• Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• Half-open stainless steel housing; visible surfaces satin finished and brushed.
• Elbow-operated disinfectant pump, can be set to different levels and autoclaved.
• Designed for standard 1000 ml disposable bottles of disinfectant.
• Accessible for refilling from the front side. Lockable cover plate in stainless steel as an option for a surcharge.
• Further accessories for a surcharge: drip tray
• Wear parts can be replaced as modules.
• Mounting: With three screws through holes in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 1,2

Ø 30 x 86 mm
projection 90 mm

• Tabletop disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished. Further available surfaces: see below.
• Design height:86 mm
  Outlet height: 68 mm
  Projection: 76 mm
• Non-drip disinfectant pump with 500 ml disinfectant bottle in plastics and pressure valve in stainless steel.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard disinfectants.
• Refillable from above by unscrewing the top part.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,7
