Floor-recessed squat WC pan, 700 x 345 x 700mm.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness 1.2mm.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
Bowl shape suitable for male and female use.
Non-slip foot area.
Vertical waste outlet: Ø 100mm.
Flushing system with one 304 stainless steel spreader.
Supplied with stainless steel trap welded to squat WC pan.
Weight: 8kg.
10-year warranty.

[Formerly ref: 0113630020]

TECHNICAL FEATURES

SHA 700 squat WC pan
Ref. 113620

Combination unit: washbasin and suspended WC pan on left side with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sidesand 1 on the top with theft prevention TORX security screws.Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.
[Formerly ref: 0610030004]

TECHNICAL FEATURES

KOMPACT washbasin and wall-hung WC combination
Ref. 160400
