448 x 1348 x 220 mm
1 paper roll / 48 l

• Combination consisting of a sensor paper roll dispenser (mains-operated) and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Paper roll dispenser with touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm. Paper length and idle time adjustable.
  Mains-operated 230 V / 50 Hz; power rating 7 Watt; mains cable on site. TÜV/GS-tested and certified.
• Designed for one paper roll with dimensions:
  Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
• Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
• Waste bin equipped with removable mesh basket.
  Capacity approx. 48 l.
• Accessible through lockable doors.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With six screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material and first fill with one paper roll.

• Weight (in kg): 25,8

Thema handle CC32mm. Available in matt chrome, brushed, polished and black. H2566

• WASTE DEPOSIT FLAP WP 154-1

  300 x 235 x 30 mm

  • Self-closing, flame-retardant waste deposit flap in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel construction; visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • No wearing parts, smooth closing by counterweight.
  • Mounting: Insert and glue into cutout.
  • Installation dimensions: 277 x 210 mm
  • Weight (in kg): 1,5

  AVAILABLE SURFACES	ORDER NUMBERS
  satin finished (standard)	727230
  highly polished	731230
  (coloured) plastic powder - coating	728230
