148 x 448 x 120 mm
950 ml bottle

• Sensor liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
• With EWAR® eModule touch-free operated soap pump.
• Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
• Also refillable with large container using the plug-in tank as an option.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, removable front panel with fall protection.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts and front panel can be replaced as modules.
• Installation dimensions: 150 x 450 x 110 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material, batteries and first fill with soap.

• Weight (in kg): 4,4

Nagi 2-ne HEWI, matt antratsiit hall 92

Väga hea värviline lahendus lasteaias, koolis või ülikoolis

Matt edition

Artiklinumber: 801.90B040

HEWI sarja 801 topeltkonks riiulipuudele Topeltkonks edaspidise riputusega konksudega, 90 mm lai, 165 mm kõrge ja 87 mm sügav, keskelt keskele 75 mm, valmistatud kvaliteetsest matt polüamiidist vastavalt HEWI värvikaardile, komplektis kinnitustarvikud.

Sarja 801 topeltkonks riiulipuudele

topeltkonks edaspidise riputusega konksudega riiete ja esemete riputamiseks 90 mm lai, 165 mm kõrge ja 87 mm sügav, keskelt keskele 75 mm valmistatud kvaliteetsest matt polüamiidist vastavalt HEWI värvikaardile

Крючок 2-х HEWI,

Отличное цветовое решение для детских садов, школ или университетов Матовое исполнение

Артикул: 801.90B040

Крючок серии 801 HEWI для полок Двойной крючок с крючками, направленными вперед, шириной 90 мм, высотой 165 мм и глубиной 87 мм, центр-центр 75 мм, изготовлен из качественного матового полиамида согласно цветовой карте HEWI, в комплекте крепежные материалы.

Серия 801 двойной крючок для полок

двойной крючок с крючками, направленными вперед для подвешивания одежды и предметов ширина 90 мм, высота 165 мм и глубина 87 мм, центр-центр 75 мм изготовлен из качественного матового полиамида согласно цветовой карте HEWI

Matt edition
Article number 801.90B040

HEWI Range 801 Double hook for cloakroom rails
double hook with forward-facing hooks, 90 mm wide, 165 mm high and 87 mm deep, centre-to-centre 75 mm, made of high-quality matt polyamide according to HEWI colour chart, supply incl. fixing materials.



Range 801 Double hook for cloakroom rails
- double hook with forward-facing hooks
- for hanging up clothing and utensils
- 90 mm wide, 165 mm high and 87 mm deep, centre-to-centre 75 mm
- made of high-quality matt polyamide according to HEWI colour chart



148 x 148 x 50 mm
for 1 sanitary bag box

• Sanitary bag dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304.
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Designed for one standard sanitary bag box with dimensions of approx. 118 x 87 x 20 mm.
• Accessible for refilling through lockable front flap.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Installation dimensions: 150 x 150 x 40 mm.
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and first fill.

• Weight (in kg): 0,8

326 x 173 x 164 mm
ca. 250 paper towels

• Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• With deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag- or c-fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Accessible for refilling through lockable front flap.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Installation dimensions: 300 x 150 mm
• Mounting: With four screws on the inside, sideways.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 3,4
