Valamu Fraju INVA R/V teras segisti avaga , ilma ülejooksuta

Käetugi 695mm sirge, harjatud R/V teras

Käetugi 695mm sirge

R/V teras AISI304

d 32mm

toru paksus 1,5mm

Pelavajutav äärikukate d 81mm

Tootekood: MBR0600CS , Tarneaeg: 7 päeva , Viimistlus:

69,11 €

Käetugi 738 mm ülestõstetav valge BG2800

Käetugi 738mm ületõstetav

teras valge epoksükate

d 32mm

toru paksus 1,5mm

Pelavajutav äärikukate d 85mm

Tootekood: MBG2800 , Tarneaeg: 7 päeva , Viimistlus:

152,46 €

Seebidiosaator kontaktivaba BJÖRK, valge-OSLO kate

PRODUCT DESCRIPTION

• Winner of a Red Dot Design Award!

• Holds approx. 9,5 dl liquid soap (= 800-950 doses).

• Battery-operated. Connection to power supply via a transformer.

• An intelligent sensor automatically sets the best sensor range.

• LED light indicates when dispenser is in use.

• Comes in trendy matt black and classic white as standard.

• Also available in all RAL colours and coated with different prints.

• Top plate in 6 optional standard designs.

• 2-year warranty.

SPECIFICATIONS
Product number:	3050 / EAN no. 5-709818-030500
Technical data:	Touch-free soap dispenser for liquid soap/disinfectant. White-painted steel housing (RAL 9003, gloss 60). Equipped with top plate. Capacity: 9,5 dl. Battery-operated.
Dimensions	H: 330 mm, W: 139 mm, D: 127 mm
Net Weight:	2.3 kg

Tootekood: DAN3050 00 , Tarneaeg: 14-21 päeva , Viimistlus:

502,10 €

AZP Brno adapter 1-3 punkte

	ZAC 1/20, ZAC 1/50, ZAC 1/36L power supply

ZAC is a safe source of voltage supply intended to power automatic sanitary equipment made by AZP Brno, Ltd.

The source of power supply consists of a safety transformer produced in accordance with ČSN IEC 742+A1 standards. All kinds of sensors can be connected to these sources in random combinations, as can other devices with a supply voltage of 12 V, 50 Hz (total power requirement either 20 VA, 50 VA or 36 VA).

ZAC 1/20 and ZAC 1/50 are independent sources, 1/36L ZAC is the source for the location on the DIN-rail (4 modules).

Version types
ZAC 1/20 - source of power supply with output 20 VA
ZAC 1/50 - source of power supply with output 50 VA
ZAC 1/36L - source of power supply with output 36 VA

Source of power supply can be placed at a maximum distance of 30 m from the connected appliance.

Basic technical information
Input voltage:	230 V, 50 Hz
Output voltage:	12 V, 50 Hz
Power requirement:	20 VA (ZAC 1/20)
	50 VA (ZAC 1/50)
	36 VA (ZAC 1/36L)
Electricity protection:	IP 55 (ZAC 1/20, ZAC 1/50)
	IP 20 (ZAC 1/36L)
Weight:	0,8 kg (ZAC 1/20, ZAC 1/36L)
	1,2 kg (ZAC 1/50)

Requirements for setting up the construction

ZAC 1/20, ZAC 1/50

Set-up supply of electricity 230 V,50 Hz – cable CYKY 3Cx1,5
Set-up niche for flush mounting – size as per installed source
Distribution to each device is carried out by cable CYKY 2Ax1,5

ZAC 1/36 L

It is installed on the DIN-rail - width of 4 modules

Figure
ZAC 1/20

ZAC 1/50

Product title

ZAC 1/20 -

power supply for up to 3 devices - 230V, 50Hz

ZAC 1/50 -

power supply for up to 8 devices - 230V, 50Hz

ZAC 1/36L -

power supply for up to 6 devices - 230V, 50Hz

Tootekood: AZP-ZAC 1-20 , Tarneaeg: 3-4 nädalad , Viimistlus:

106,72 €
