Range: Outdoor shower column

Ref: 29910 - PRESTO S4

> Working pressure :

From 2 to 5 bar

> Flow rate :

10 l/min at 3 bar by integrated flow rate limiter Anti-water-hammering design

> Flow time :

20 seconds (± 5 sec.)

> Hydraulic supply :

Femelle G 3/4" (20x27) on stop-valve
On 4 special P12A shower single taps and 4 shower heads (29301)

> Material and colour finish :

High density polyethylene body with gel-coating and blue colored in the mass, UV resistant. Nickel-chrome plated on brass body and components

> Thermal resistance :

Resistant to a temperature of 75°C for 30-minute-thermal-shocks

> Security :

Non rotating knob avoiding premature wear

> Delivered with :

Wood packaging (reusable for winter storing) 1 stop valve with female 3/4" purge (20x27) Hoses
Instruction manual

> Standards & approvals :

Molded chrome-plated body in accordance with EN 12540
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227

> Working pressure :

1 to 5 bar

> Flow :

3 l/min with integrated flow limiter High quality anti-limescale aerator Anti-water-hammering design

> Hydraulic supply :

G 3/8" (12x17)

> Power supply :

230 VAC / 7 VDC transformer in IP65 waterproof case

> Material and colour finish :

Injected molded metal body and cover Chrome finishing

> Thermal resistance :

Resistant to a temperature of 75°C for 30 minute thermal shocks

> Security :

Temperature limiting system to avoid any risk of scalding Anti-overflow security time is set to 30 seconds
Anti-blocking system preventing the water to flow continuously

> Delivered with :

1 Brass clamping nut
1 Gasket and 1 Washer
2 PEX Hoses with revolving nuts and NF check valves 2 MM G 3/8" (12x17) Stop valves
2 Filter gaskets
1 Self-adhesive sticker
Instruction manual

> Standards & approvals :

Molded chrome-plated body in accordance with EN 12540
Brass in accordance with NF EN1982, EN12164, EN12165
200-hour neutral salt spray resistant (NSS) in accordance with NF ISO 9227
