86 x 298 x 121 mm

• Sensor liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• With EWAR® eModule touch-free operated and non-drip soap pump.
• Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With three screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, batteries and first fill with soap.

• Weight (in kg): 2,8

148 x 348 x 150 mm
with concealed reserve roll

• Toilet roll holder with one concealed reserve roll in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded. Visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Designed for two standard toilet rolls, including one concealed reserve roll, which drops down automatically with dimensions:
  Outer diameter max. 125 mm
  Width max. 100 mm
  Core diameter min. 38 mm
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable front flap.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Installation dimensions: 150 x 350 x 140 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material.

• Weight (in kg): 3,2
