380 x 1350 x 380 mm
950 ml tank

• Hygiene station consisting of a sensor-disinfectant dispenser and a floor-stand in robust, germ-reducing and easy-care stainless steel.
• Visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor-disinfectant dispenser in stainless steel (AISI316L) with rounded vertical corners.
  • With EWAR® eModule touch-free operated disinfectant pump with 950 ml tank.
  • Designed for standard disinfectants.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable, hinged housing.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  • Wear parts can be replaced as modules.
  • Delivery includes batteries.
• Floor-stand in stainless steel (AISI304)
  • Base plate with rubber feet.
  • Intended for free floor installation.

• Weight (in kg): 10,1

Tualettharjahoidel. Portselan

Must handle CC128mm. Available in brushed, polished, matt chrome and black. H2533

Ø 45 x 170 x 185 mm
normal pressure

• Single-lever basin tap without waste fitting in robust, germ-reducing and easy-care stainless steel (AISI 303).
• Version: normal pressure. Operating pressure 2–6 bar.
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• High quality ceramic mixer cartridge with adjustable temperature limit setting (scald protection).
• Neoperl® air bubble spray M21 x 1 mm.
• Design height: 171 mm
  Outlet height: 87 mm
  Projection: 98 mm
  Length of lever: 140 mm
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 33-40 mm
  Surface thickness max. 40 mm
• Mounting: With one counternut.
• Delivery includes fixing material and two flexible connecting hoses clad in stainless steel.

• Weight (in kg): 1,60
