Delabie valamu CANAL 2400mm, R/V teras (4 kohta)

CANAL wall-mounted wash trough
Ref. 120300

Wall-mounted wash trough for 4 posts - 2,400mm
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1mm for the bowl, 1.5mm for surroundand fixing brackets.
Easy to install: no joint concealers to install, light wash trough.
Drainage on the right.
With no tap hole.
Supplied with 1 ½" waste.
Without overflow.
Supplied with brackets and fixing elements.
CE marked. Complies with European standard EN 14296.
Weight: 20kg.
Possible to add a bacteriostatic 304 stainless steel splashback (ref. 0011800007).

Height	250mm
Length	2400mm
Width	400mm
Thickness	1mm (basin) et 1.5mm (edge and fixing brackets)
Finish	304 polished satin stainless steel

Tootekood: DE-120300 , Tarneaeg: 14-21 päeva

1115,10 € (10%)
1239,00 €

Pissuaari mehhanism infra-red paigalduse karbiga, 24 V DC

SLP 02K

Urinal infra-red flushing unit with a mounting box, 24 V DC

Characteristics

system reacts to the user attendance in front of the urinal at a maximum distance of 0,7 m, minimum stay time in active range is 7,5 s
water flows after the user leaves active range
adjustable flushing time 0,5 - 15,5 s
parameters adjustment by remote control SLD 03
automatic hygiene flushing after 24 hours non-use
possibility to regulate a water flow by the ball valve

Order number	01022
Code	SLP 02K

Supply specification

SLP 02K - Supply No. 01022 - stainless steel cover with electronics, plastic mounting box with brass screw coupling, electromagnetic valve and ball valve

Technical information

Stainless steel cover dimension: 170 x 170 x 10 mm
Mounting box dimension:140 x 140 x 75 mm
Operating voltage: 24 V DC
Active range: 0,6 - 0,75 m
Recommended flow pressure: 0,1 - 0,6 MPa
Rate of flow: 18 l/min (inf. data)
Water inlet: male thread G 3/4“
Water outlet: male thread G 3/4“

Tootekood: SA-SLP02K , Tarneaeg: 14-21 päeva

355,00 €

Joogifontään seinale mehaaniline R/V teras AISI316 (basseinid)

AFO 01 stainless steel wall-mounted drinking fountain

AFO 01 is a stainless steel wall-mounted drinking fountain of modern design with a manual press valve that allows its easy use. The water flows only when the valve is pressed and then there is a certain adjusted time to rinse out the nozzle.
The water inlet is fitted with a flexible hose, the siphon is made from a stretchy, flexible connector. The flexible finish of the water inlet and outlet allows the variable and problem-free connection of the fountain.
AFO 01 stainless steel fountain is suitable mainly for schools, medical facilities and spa resorts, and is utilizable outdoors.
AFO 01 is made of stainless steel AISI 304.
AFO 01.CL is made of stainless steel AISI 316 and is suitable into the areas with higher concentration of chlorine (e.g. swimming pools).
Sensor-controlled fountain possible made to order.
For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).

Package contents

stainless steel sink with casing
press valve
corner valve with filter
flexible hose siphon
fixing bar
connecting hoses
anchoring material

Water inlet	G 1/2"
Water pressure	0,2 – 0,6 MPa (recommended 0,3 MPa)
Outlet	d = 40 mm
Inner dimension of the fountain	d = 245 mm
Weight	4 kg

Tootekood: AZP-AF001.CL , Tarneaeg: 3-4 nädala

1075,00 €

Joogifontään seinale sensoriga R/V teras AISI304 6V(4x1.5V)

AFO 01.Yst. steel sensor controlled drinking fountain

AFO 01.Y is st. stainless wall hung drinking fountain controlled by sensor. Water runs after disrupting the scanning zone.

Fountain is made by welding all components together.

Fountain is suppplied with safety power 12 V, 50 Hz from power supply ZAC (AFO 01.Y) or with 4x AA battery (AFO 01.YB).

Material is standardly st. steel AISI 304 or can be AISI 316 (AFO 01.Y.CL or AFO 01.YB.CL).

St. steel driking fountain AFO 01.Y is based on favourite model AFO 01 with manual control.

The sensor, located on the right side of the fountain, is reacting on the approach of the user. Water starts to run from the nozzle, located in the middle of the fountain bowl, and runs over the time when the user´s head is in the scanning zone (max. 30 sec.) + preset time (max. 4 sec.) to clean the nozzle.

Package contents

st. steel drinking fountain
nozzle
sensor and electronic
electromagnetic valve
connecting flexible hose
corner valve with filters
siphon
mounting material

water inlet	G 1/2"
water pressure	1 - 10 Bar (AFO 01.Y; AFO 01.Y.CL)
	2 - 8 Bar (AFO 01.YB; AFO 01.YB.CL)
outlet	d = 40 mm
bowl inner dimension	d = 245 mm
weigth	4 kg
suppply	12 V, 50 Hz (AFO 01.Y; AFO 01.Y.CL)
	6 V - 4 x AA battery (AFO 01.YB; AFO 01.YB.CL)
power supply	ZAC 1/20 (max. 3 x AFO 01.Y ; AFO 01.Y.CL)

Tootekood: AZP-AFO01.YB , Tarneaeg: 3-4 nädala

927,00 €

Joogifontään free-standing mehaaniline R/V teras AISI316

AFO 02 - IIstainless steel free-standing drinking fountain (indoor/outdoor)

AFO 02-II is a stainless steel drinking fountain of modern design with a manual press valve that allows its easy use. The water flows only when the valve is pressed and then there is a certain adjusted time to rinse out the nozzle.
The drinking fountain is to be placed in an open space. It is made up of an anchoring part intended for embedding in concrete and the column itself with a press valve and nozzle. These parts are connected by means of 3 screws and the upper part can be, therefore, easily dismounted in case of necessity (e.g. during winter).
The water inlet is fitted with a flexible hose, the siphon is made from a stretchy, flexible connector. The flexible finish of the water inlet and outlet allows the variable and problem-free connection of the fountain.
AFO 02-II stainless steel fountain is suitable mainly for schools, medical facilities and spa resorts, and is utilizable outdoors.
Drinking fountain AFO 02-II is manufactured from the stainless steel AISI 304. AFO 02.CL-II is made of the stainless steel AISI 316 and is suitable for places with higher concentration of chlorine.
For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).Detail of the bowl

Package contents

stainless steel column and cone with nozzle
press valve
anchoring construction
flexible hose siphon
connecting hoses
anchoring material

Set-up water inlet - pipe G 1/2“
Set-up drainage d = 40 mm
Prepared alcove for embedding (concreting) in the base construction

Water inlet	G 1/2"
Water pressure	2 – 6 Bar, recommended 3 Bar
Outlet	d = 40 mm
Inner dimensions of sink	d = 290 mm
Weight	20 kg

Tootekood: AZP-AFO02.CL , Tarneaeg: 3-4 nädalad

1903,00 €
