General description

•   White epoxy-coated grab bars curved in 90o, to be installed on the wall, with Polypropylene snap flanges and made of Ø 32 mm steel tube.

•   These grab bar make the daily life-management of not only the disabled and elderly people easier but also it is a great support for everybody who needs help with moving.

•   Especially designed to achieve barrier-free accessibility in bathrooms and public spaces.

•   With three snap flanges, made of white Polypropylene that provide a clean finished look hiding the mounting screws.

•   Easy to clean.

•   Optionally, they have a kit to avoid electrical conductivity (code KA0010).

•   Fixing screws for brick wall included.

  Components and materials

•   BAD090C & BAI090C: right hand grab bar made of steel, white finish.

•   BAD090CS & BAI090CS: left hand grab bar made of steel, white finish.

•   TUBING: made of 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter

  along the bends.

•   CONCEALED MOUNTING FLANGE: three units made of steel, 3 mm thick. Incorporates two Ø 6.5 mm screws holes for wall

  mounting.

•   SNAP FLANGE COVER: three units made of Polypropylene, 1.5 mm thick and Ø 85 mm. Each cover snaps over mounting flange

General description

•   Wall to wall grab bar with three support points, made of diameter 32 mm AISI 304 stainless steel tube, to be installed in the washbasins and toilets.

•   With snap flange covers to conceal the screws, helping to achieve a beautiful and sleek look and protecting the flange surfaces from damage, dust, moisture and foreign particles.

•   Ideal to design barrier-free accessibility, both domestic and commercial places, these grab bars help make the lives easier for the handicapped and elderly people.

•   Highest durability and rusting resistance.

•   Optionally, these bars can be electrically isolated by installing the electrical isolation Kit code KA0020.

•   These grab bars are supplied with a kit to fix the bar to a brick wall.

  Components and materials

•   BFD600C: grab bar right hand, made of diameter 32 mm AISI 304 stainless steel tube, bright finish.

•   BFI600C: grab bar left hand, made of diameter 32 mm AISI 304 stainless steel tube, bright finish.

•   BFD600CS: grab bar right hand, made of diameter 32 mm AISI 304 stainless steel tube, satin finish.

•   BFI600CS: grab bar left hand, made of diameter 32 mm AISI 304 stainless steel tube, satin finish.

•   TUBING: made of 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter along the bends.

•   CONCEALED MOUNTING FLANGE: three units made of AISI 304 stainless steel, 3 mm thick. Incorporates two Ø 6.5 mm screws holes for wall mounting.

•   SNAP FLANGE COVER: three units made of stainless steel AISI 304, 0.8 mm thick and Ø 82 mm. Each cover snaps over mounting flange to conceal mounting screws.
