Roostevaba teras valamu KEG

2-ne Valamu jalaga 1200x700, kõrgus 850mm , R/V teras

Нержавеющая большегрузная двойная мойка на ножках, 1200 x 700 x 850 мм

Характеристики

stainless steel bulk double-sink with a sheating
without a tap hole (could be made to order)
possibility of fine plane regulation by the regulation screws on the supporting legs
possibility to order inner sinks in dimensions: 400 x 300 x 200 mm/ 400 x 400 x 250 mm/ 400 x 400 x 200 mm
available also in the length 1400 mm
material CrNi 18/10 (AISI-304)
brushed finish
different dimensions could be made to order

Арт. №	93160
Название	SLUN 16

Tootekood: SA-SLUN16 , Tarneaeg: 3-5 nädalad , Viimistlus:

2790,00 €

AZP Brno adapter 1-3 punkte

	ZAC 1/20, ZAC 1/50, ZAC 1/36L power supply

ZAC is a safe source of voltage supply intended to power automatic sanitary equipment made by AZP Brno, Ltd.

The source of power supply consists of a safety transformer produced in accordance with ČSN IEC 742+A1 standards. All kinds of sensors can be connected to these sources in random combinations, as can other devices with a supply voltage of 12 V, 50 Hz (total power requirement either 20 VA, 50 VA or 36 VA).

ZAC 1/20 and ZAC 1/50 are independent sources, 1/36L ZAC is the source for the location on the DIN-rail (4 modules).

Version types
ZAC 1/20 - source of power supply with output 20 VA
ZAC 1/50 - source of power supply with output 50 VA
ZAC 1/36L - source of power supply with output 36 VA

Source of power supply can be placed at a maximum distance of 30 m from the connected appliance.

Basic technical information
Input voltage:	230 V, 50 Hz
Output voltage:	12 V, 50 Hz
Power requirement:	20 VA (ZAC 1/20)
	50 VA (ZAC 1/50)
	36 VA (ZAC 1/36L)
Electricity protection:	IP 55 (ZAC 1/20, ZAC 1/50)
	IP 20 (ZAC 1/36L)
Weight:	0,8 kg (ZAC 1/20, ZAC 1/36L)
	1,2 kg (ZAC 1/50)

Requirements for setting up the construction

ZAC 1/20, ZAC 1/50

Set-up supply of electricity 230 V,50 Hz – cable CYKY 3Cx1,5
Set-up niche for flush mounting – size as per installed source
Distribution to each device is carried out by cable CYKY 2Ax1,5

ZAC 1/36 L

It is installed on the DIN-rail - width of 4 modules

Figure
ZAC 1/20

ZAC 1/50

Product title

ZAC 1/20 -

power supply for up to 3 devices - 230V, 50Hz

ZAC 1/50 -

power supply for up to 8 devices - 230V, 50Hz

ZAC 1/36L -

power supply for up to 6 devices - 230V, 50Hz

Tootekood: AZP-ZAC 1-20 , Tarneaeg: 3-4 nädalad , Viimistlus:

106,72 €

Pissuaari mehhanism infra-red paigalduse karbiga, 24 V DC

SLP 02K

Urinal infra-red flushing unit with a mounting box, 24 V DC

Characteristics

system reacts to the user attendance in front of the urinal at a maximum distance of 0,7 m, minimum stay time in active range is 7,5 s
water flows after the user leaves active range
adjustable flushing time 0,5 - 15,5 s
parameters adjustment by remote control SLD 03
automatic hygiene flushing after 24 hours non-use
possibility to regulate a water flow by the ball valve

Order number	01022
Code	SLP 02K

Supply specification

SLP 02K - Supply No. 01022 - stainless steel cover with electronics, plastic mounting box with brass screw coupling, electromagnetic valve and ball valve

Technical information

Stainless steel cover dimension: 170 x 170 x 10 mm
Mounting box dimension:140 x 140 x 75 mm
Operating voltage: 24 V DC
Active range: 0,6 - 0,75 m
Recommended flow pressure: 0,1 - 0,6 MPa
Rate of flow: 18 l/min (inf. data)
Water inlet: male thread G 3/4“
Water outlet: male thread G 3/4“

Tootekood: SA-SLP02K , Tarneaeg: 14-21 päeva , Viimistlus:

360,82 €

Joogifontään free-standing mehaaniline R/V teras AISI316

AFO 02 - IIstainless steel free-standing drinking fountain (indoor/outdoor)

AFO 02-II is a stainless steel drinking fountain of modern design with a manual press valve that allows its easy use. The water flows only when the valve is pressed and then there is a certain adjusted time to rinse out the nozzle.
The drinking fountain is to be placed in an open space. It is made up of an anchoring part intended for embedding in concrete and the column itself with a press valve and nozzle. These parts are connected by means of 3 screws and the upper part can be, therefore, easily dismounted in case of necessity (e.g. during winter).
The water inlet is fitted with a flexible hose, the siphon is made from a stretchy, flexible connector. The flexible finish of the water inlet and outlet allows the variable and problem-free connection of the fountain.
AFO 02-II stainless steel fountain is suitable mainly for schools, medical facilities and spa resorts, and is utilizable outdoors.
Drinking fountain AFO 02-II is manufactured from the stainless steel AISI 304. AFO 02.CL-II is made of the stainless steel AISI 316 and is suitable for places with higher concentration of chlorine.
For cleaning we recomnned WÜRTH detergents – material preservation (no. 0893 121 K) and material cleaning (no. 893 121 1).Detail of the bowl

Package contents

stainless steel column and cone with nozzle
press valve
anchoring construction
flexible hose siphon
connecting hoses
anchoring material

Set-up water inlet - pipe G 1/2“
Set-up drainage d = 40 mm
Prepared alcove for embedding (concreting) in the base construction

Water inlet	G 1/2"
Water pressure	2 – 6 Bar, recommended 3 Bar
Outlet	d = 40 mm
Inner dimensions of sink	d = 290 mm
Weight	20 kg

Tootekood: AZP-AFO02.CL , Tarneaeg: 3-4 nädalad , Viimistlus:

1934,20 €

Delabie valamu pool uputatud QUADRA 380x380, R/V teras AISI304

Semi-recessed QUADRA washbasin
Ref. 120650

Semi-recessed washbasin, 380x380mm.
Suitable for use with wall-mounted or extended mixer/tap.
Basin internal diameter: 310mm.
Cutout diameter: 310mm.
Stainless steel thickness: 1.2mm.
Polished satin finish.
Stainless steel thickness: 1.2mm.
One-piece, seam-free pressed bowl.
Rounded edges prevent injury.
Supplied with 1¼" waste.
Without overflow.
CE marked. Complies with European standard EN 14688.
Weight: 3kg.

TECHNICAL FEATURES

Semi-recessed QUADRA washbasin
Ref. 120650

Height	130mm
Length	380mm
Width	380mm
Thickness	1.2mm
Finish	Polished satin 304 stainless steel

Tootekood: DE-120650 , Tarneaeg: 14-21 päeva , Viimistlus:

620,00 €
