170 x 170 x 100 mm

• Waste disposal frame in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel construction; visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Mounting: Insert and glue into cutout.
• Installation dimensions: 150 x 130 mm

• Weight (in kg): 0,7

298 x 1198 x 220 mm
ca. 500 paper towels / 32 l

• Combination consisting of a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 500 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Waste bin equipped with removable mesh basket. Capacity approx. 32 l. Accessible through lockable door.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 300 x 1200 x 210 mm (when fully fitted).
• Mounting: With six screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and one pack of paper towels.

• Weight (in kg): 14,7

353 x 350 x 120 mm

• Four-fold toilet roll holder in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; visible surfaces satin finished and brushed. Further available surfaces: see below.
• Designed for four standard toilet rolls with dimensions:
  Outer diameter max. 125 mm
  Width max. 100 mm
  Core diameter min. 38 mm
• Three concealed reserve rolls, each dropping down automatically.
• Inspection slot to indicate fill level.
• Accessible for refilling through lockable, hinged housing.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.
• Can be converted to WP163 at a later time: Conversion kit ID 923 291.

• Weight (in kg): 6,1

125 x 89 x 45 mm

• Soap shell in solid, germ-reducing and easy-care stainless steel (AISI 303), satin finished.
  Further available surfaces: see below.
• Concealed anti-theft two-point rosette wall mounting.
• Holder diameter 16 mm
  Shell diameter 89 mm
  Height 18 mm
• Mounting with two screws.
• Delivery includes fixing material.

• Weight (in kg): 0,60
