1417.0050

Linear 1417.0050

Ø 50 mm horizontal drain

The odour barrier can be removed for cleaning

Can be rotated 180 degrees if a rear-facingoutlet is required Note:

Odour barrier is VA-approved

Ø 30 x 86 mm
projection 76 mm

• Tabletop disinfectant dispenser in chrome-plated brass.
• Solid body in brass; visible surfaces high-gloss chrome-plated.
• Design height:86 mm
  Outlet height: 68 mm
  Projection: 76 mm
• Non-drip disinfectant pump with 500 ml disinfectant bottle in plastics and pressure valve in brass.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard disinfectants.
• Refillable from above by unscrewing the top part.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm,
  surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 0,7

148 x 148 x 120 mm
1000 ml soap tank

• Liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• One-hand operated and non-drip soap pump with 1000 ml tank and pressure valve in brass.
• Tank with large, lockable refill opening.
• Designed for standard liquid soaps.
• Accessible for refilling through lockable, removable front panel with fall protection.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material.

• Weight (in kg): 2,0
