Tootegrupid

Delabie Be-line ülestõstetav invatugi D42mm L850mm Antracite aluminim

Tootekood: DE-511964C
Kaubamärk:
Ühik: tk
Tarneaeg: 14-21 päeva
Hind:
406,00 €
Kogus: - +
   - või -

Be-Line drop-down support rail, L. 850mm, anthracite
Ref. 511964C

Be-Line drop-down support rail for people with reduced mobility.
In the lowered position use as a grab bar, as a support for standingand for assisting movement, for WCS or showers.
Allows side access in the raised position.
Removable: easy to remove with anti-theft locking system. Reduces the number of barsin a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.
Slowed down descent. Retained in upright position.
Aluminium tube.
Rounded profile Ø 42mm with ergonomic flat front face that prevents rotation for an optimal grip.
Metallised anthracite powder-coated aluminium finish provides a good visual contrast with the wall.
Uniform surface for easy maintenance and hygiene.
Concealed fixings secured to wall by a 304 stainless steel plate, 5mm thick.
Supplied with stainless steel screws Ø 8 x 70mm for concrete walls.
Dimensions: 850 x 210 x 120mm.
Tested to over 200kg. Maximum recommended user weight: 135kg.





TECHNICAL FEATURES

Be-Line drop-down support rail, L. 850mm, anthracite
Ref. 511964C

Height 210mm
Length 850mm
Width 120mm
Finish Powder-coated metallised anthracite aluminium

Failid

Kokku sobivad tooted

DESCRIPTION

Cover plate for Be-Line drop-down rail
Ref. 511950C

Be-Line metallised anthracite cover plate without fixings plate.
Conceals fixing screws when the drop-down support rail is removed.
Reduces the number of drop-down rails in a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.



TECHNICAL FEATURES

Cover plate for Be-Line drop-down rail
Ref. 511950C

Height 230mm
Depth 17mm
Width 105mm
Finish Metallised anthracite
Tootekood: DE-511950C ,   Tarneaeg: 14-21 päeva
51,00 €

Cover plate for Be-Line drop-down rail with fixings plate
Ref. 511950FC

Be-Line metallised anthracite cover plate with fixings plate.
Conceals fixing screws when the drop-down support rail is removed.
Reduces the number of drop-down rails in a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.
Supplied with stainless steel screws for concrete walls.



TECHNICAL FEATURES

Cover plate for Be-Line drop-down rail with fixings plate
Ref. 511950FC

Height 230mm
Depth 17mm
Width 105mm
Finish Metallised anthracite
Tootekood: DE-511950FC ,   Tarneaeg: 14-21 päeva
98,00 €

Cover plate for Be-Line drop-down rail
Ref. 511950W

Be-Line matte white cover plate without fixings plate.
Conceals fixing screws when the drop-down support rail is removed.
Reduces the number of drop-down rails in a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.

TECHNICAL FEATURES

Cover plate for Be-Line drop-down rail
Ref. 511950W

Height 230mm
Depth 17mm
Width 105mm
Finish Matte white
Tootekood: DE-511950W ,   Tarneaeg: 14-21 päeva
51,00 €

Cover plate for Be-Line drop-down rail with fixings plate
Ref. 511950FW

Be-Line matte white cover plate with fixings plate.
Conceals fixing screws when the drop-down support rail is removed.
Reduces the number of drop-down rails in a facility, allowing installation only when required.
Example: hotels or hospitals providing short-term accommodation for people with reduced mobility.
Supplied with stainless steel screws for concrete walls.



TECHNICAL FEATURES

Cover plate for Be-Line drop-down rail with fixings plate
Ref. 511950FW

Height 230mm
Depth 17mm
Width 105mm
Finish Matte white



Tootekood: DE-511950FW ,   Tarneaeg: 14-21 päeva
98,00 €
Sarnased tooted

Käetugi 400mm valge , nylon

Tootekood: P60402 ,   Tarneaeg: 2-7 päeva
30,00 €

Nova2 Care


Height: 145mm
Width: 490mm
Depth: 380mm
Weight: 20 kg.
Design: Bønnelycke mdd
Tootekood: FRON1963-B ,   Tarneaeg: 14-21 päeva
588,05 € (5%)
619,00 €
  1. Components y materials

    •   FOLDING BAR: folded in a trapezoidal shape and manufactured with a 32 mm diameter AISI 304 stainless steel tube satin finish. Both bar ends are welded to the vertical column, made of a 32 mm diameter stainless steel AISI 304 tube. The grip zones of the bar have a safety anti-slip finish to improve the user safety. It incorporates a paper roll holder 120 mm length, made of a 6 mm diameter AISI 304 stainless steel rod.

    •   WALL MOUNTING PLATE: made of an AISI 304 stainless steel satin finish rectangular plate of 125 x 100 mm and 10 mm thick. It incorporates four Ø 8 mm countersunk holes, to fix the bar to the wall.

    •   FLOOR MOUNTING PLATE: made of an AISI 304 stainless steel satin finish circular plate of Ø 75 mm and 5 mm thick. It incorporates three Ø 7 mm countersunk holes to fix the bar on the floor.

    •   UNLOCK HANDLE: made of black thermoplastic.

BG0089CS Satin finish

Technical specifications

Dimensions

Grab bar and column diameter Wall mounting plate thickness Floor mounting plate thickness Paper roll holder diameter

700 x 835 x 100 mm

Ø 32 mm 10.0 mm 5.0 mmØ 6.0 mm

Tootekood: MBG0089CS ,   Tarneaeg: 7 -14 päeva
415,15 € (5%)
437,00 €

General description

  •   Wall-floor grab bar, with three support points, made of a diameter of 32 mm AISI 304 stainless steel tube, bent in an "L" shape at 90o and with a 32mm diameter lateral arm, welded on the lower part of the grab bar and also bent at 90°.

  •   With snap flange covers that conceal the installation screws, improving the aesthetics of the bars once installed on the wall.

  •   These grab bars offer a great safety and comfort to the user, helping to make the bathroom much safer for the elderly or those with reduced

    mobility. Models suitable for public use.

  •   Well suited for keeping bathrooms and public enclosures barrier-free.

  •   Highest durability and great resistance to rusting.

  •   Optionally, these grab bars can be electrically isolated, installing the electrical isolation kit code KA0020.

  •   Supplied with plugs and screws to fix the bar to a brick wall.

    Components and materials

    •   BSD020C: right hand grab bar made of AISI 304 stainless steel tube, bright finish.

    •   BSI020C: left hand grab bar made of AISI 304 stainless steel tube, bright finish.

    •   BSD020CS: right hand grab bar made of AISI 304 stainless steel tube, satin finish.

    •   BSI020CS: left hand grab bar made of AISI 304 stainless steel tube, satin finish.

    •   TUBING: made of a 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the diameter along the bends.

    •   CONCEALED MOUNTING FLANGE: three units made of AISI 304 stainless steel, 3 mm thick. Incorporates two Ø 6.5 mm screw holes for wall mounting.

    •   SNAP FLANGE COVER: three units made of AISI 304 stainless steel, 0.8 mm thick and Ø 82 mm. Each cover snaps over mounting flange to conceal mounting screws.

Tootekood: MBSD020CS ,   Tarneaeg: 14 -21 päeva
170,00 €

material:AISI 304 stainless steel | finish:Satin

90º angled grab bar



Mediclinics offers these products for the purpose of improving the quality of life of people with reduced mobility.

Solutions with several ergonomics and functionalities and with the possibility of having different materials and finishes. Mediclinics offers professionals a wide range of grab bars for toilets to help persons with reduced mobility use the facilities. Within this range, two product lines are available:

Medinox Series

State of the art design, high durability and easy to maintain. The process used for bending the grab bars guarantees uniformity in the diameter of its curves. Built using AISI 304 stainless steel with a bright and satin finish.

Mediepoxy Series


Solutions manufactured with a corrosion resistant treatment, ideal for very harsh environments, with a low need for maintenance and long durability. The grab bars for toilets are made of steel with an epoxy finish.

Mediclinics grab bars for toilets include a snap flange cover for installation out of sight, offering a perfect visual finish and allowing to be easily blended in with the decoration of the room.

Apart from the grab bars for toilet, Mediclinics provides shower seats made of AISI 304 stainless steel, which are robust, safe and suitable for installation in harsh environments.
Tootekood: MBAD090C ,   Tarneaeg: 7-21 päeva
125,00 €
