Presto CHEF professionaalne köögisegisti ref.70802
Ref: 70802 - Deck-mounted single hole mixer with upward spout
> THE PRODUCT BENEFITS
Resistant to intensive use
Reinforced body / spout interface with double sliding bearings: no play and high endurance
Robust spout: 22 mm in diameter
Intuitive and ergonomic knobs: easy grip
Hygiene: spout with smooth interior
Product design
Ease of cleaning
High spout to let large containers pass
Easy maintenance: presence of a slot under the red / blue patch allowing the passage of a screwdriver Ease of maintenance: availability of all spare parts
Flow straightener to channel water and avoid lateral water splashes
> TECHNICAL SPECIFICATIONS > Model:
Deck-mounted single hole mixer with upward spout
360 ° swivel spout, projection 250 mm, height under spout 251 mm, diameter 22 mm. Spout thickness: 1.5 mm. 1/4 turn ceramic head with flow rate 37L / min at 3 bar
Interchangeable anti-tartar flow straightener
> Recommended working pressure:
1 to 5 bars
> Flow rate:
37L / min at 3 bar
> Hydraulic supply:
G 1/2 '' (15x 21)
> Material and color of finish:
Chromed brass body and spout Material compliant with the "UBA" list
> Thermal resistance :
Withstands a temperature of 75 ° C for 30 minutes (as part of thermal shock).
> Delivered with:
1 fixing bracket
2 PEX flexible hoses with stainless steel braided nut G1 / 2 '' Lg 660 mm with non-return valves NF 2 filters
> Option:
Possibility of adding an extension sold separately, facilitating the passage of large containers
> Standards and approvals:
Chromed brass body compliant with standards NF EN1982 / NF EN 12164 / NF EN 12165 Nickel-Chrome surface treatment according to NF EN12540
Resistance to neutral salt spray (NSS): 200 h according to NF ISO 9227
Failid
Vola Köögi kangsegisti KV1, Kollane RAL 1023
Kangsegisti keraamilise töörganiga
Kahes suuna pööratava jooksutoruga.
Toru mõõt: 10 mm
Paigaldusava:30mm, max.35mm
Slate
Köögisegisti, sisaldab X-ChangeTMühendust
- Artikli number 6509774
- Viimistlused Kroom/must, Kroom
- Standardfunktsioonid
- Keraamiline tööorgan.
- Põletuskaitsega
- Veesäästu funktsioon Eco-Save.
- Pööratava jooksutoru peaga.
- Külm start.
- Pööratav jooksutoru.
- 120° pöördepiiraja.
- Kummiaeraator – lihtne puhastada.
244,00 €
Characteristics
- stainless steel wall hung cleaner‘s sink
- with splash-back and grating
- overflow set
- waste output Ø 50 mm
- material CrNi 18/10 (AISI-304)
- brushed finish
Order number | 98010 |
Code | SLVN 01 |
Характеристики
- stainless steel wall hung cleaner‘s sink
- with splash-back and grating
- overflow set
- waste output Ø 50 mm
- material CrNi 18/10 (AISI-304)
- brushed finish
Арт. № | 98010 |
Название | SLVN 01 |
Kangsegisti keraamilise töörganiga
Kahes suuna pööratava jooksutoruga.
Paigaldusava:42mm, jooksutorule: 22mm
Deck-mounted single hole mixer - 45 lpm
Ref. 5640T3
Deck-mounted single hole mixer with swivelling, tubular spout Ø 22mm H. 190mm L. 300mm.
Star-shaped flow straightener.
Water-free, guided valve heads with reinforced mechanisms.
Shock-resistant, ergonomic ball levers.
Flow rate 45 lpm at 3 bar.
Full flow rate achieved within first 90°.
Spout with smooth interior.
Chrome-plated brass body and spout.
Reinforced fixings via two stainless steel rods.
F3/8" PEX flexibles.
