> Working pressure :

1 to 5 bar

> Flow rate:

6l/min with integrated flow limiter Anti-water-hammering device
Hand-held shower on rail with chrome plated slide

> Flow time:

30 seconds (adjustable from 1 sec to 5 min) and Start/Stop function Adjustable duration and frequency of the "duty flush" function

> Hydraulic supply :

G 1/2" (15x21), top or rear water inlet. For rear water inlet, we recommend to add the adaptation kit under the reference 91026 On the PRESTO TOUCH® tapware and EN 1111 thermostatic mixer tap with NF check valves

> Power supply:

6 V Lithium battery type CRP2 in a case integrated inside the panel

> Material :

Anodised aluminium extruded section (2.5mm thickness) Aluminium removable valve plate, peinted RAL 7005 colour High resistance RAL 7005 coloured ABS covers

> Functioning:

Wide opening panel without the need to dismantle from the wall and shower taps on a removable valve plate

> Thermal resistance :

Resistant to a temperature of 70°C during 30 minutes (for 20 cycles) in case of thermal shocks

> Security :

WATER NETWORK SECURITY : no cross-connection between hot water and cold water (only in Mastermix technology). Two solenoid valves allow to isolate the hot water and cold water.
ANTI-SCALDING SAFETY : flow is immediately stopped if the cold water or hot water is cut off, compliant to French norm EN1111. Integrated temperature switch limiter will not deliver pre-mixed water above 38°C.

Possibility to parameter the periodical flushing in term of frequency or flow time
The solenoid valve closes automatically if the battery runs out or the sensor is damaged

> Delivered with :

1/2" hoses with revolving nuts
MM 1/2" (15x21) straight stop valves and 250 micron filters Fastening screws and instruction manual

> Standards & approvals :

Brass body in accordance with EN 1982, EN 12164, EN 12165 Chrome-plated surface treatment in accordance with EN 12540 200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227
