Dušitugi L-kujuline 800x800x70 RST harjatud matt
Horisontaalne nurga käetugi, 3-punkti kinnitus. Toru d 32 mm.
• 90º wall to wall horizontal grab bar for showers, baths and changing rooms, with three anchoring points and with snap flange covers, made with stainless steel tube, folded in an "L" shape at 90º.
• Designed to achieve barrier-free accessibility in bathrooms and public spaces. This grab bar is suitable for specific spaces for the elderly or people with reduced mobility. Model suitable for collectivities.
• Stainless steel gives this bar great durability and great resistance to rust.
• The bar has three snap flange covers that conceal the anchoring screws to the wall and reinforce, even more, the beauty of the product once installed.
• Optionally, these bars can be electrically isolated by installing the Electrical Isolation Kit code KA0020.
• Supplied with all the necessary hardware to fix the bar to a brick wall.
General description
Mediepoxi / Medinox series
BD0700C BD0700CS Bright finish Satin finish
90o wall to wall horizontal grab bar for showers, baths and changing rooms, with three anchoring points and with snap flange covers, made with stainless steel tube, folded in an "L" shape at 90o.
Designed to achieve barrier-free accessibility in bathrooms and public spaces. This grab bar is suitable for specific spaces for the elderly or people with reduced mobility. Model suitable for collectivities.
Stainless steel gives this bar great durability and great resistance to rust.
The bar has three snap flange covers that conceal the anchoring screws to the wall and reinforce, even more, the beauty of the product once
installed.
Optionally, these bars can be electrically isolated by installing the Electrical Isolation Kit code KA0020.
Supplied with all the necessary hardware to fix the bar to a brick wall.
Components and materials
BD2700: 90o wall to wall horizontal grab bar with three anchoring points, made with AISI 201 stainless steel tube white finish.
BD2700B: 90o wall to wall horizontal grab bar with three anchoring points, made with AISI 201 stainless steel tube matte black finish.
BD0700C: 90o wall to wall horizontal grab bar with three anchoring points, made with AISI 304 stainless steel tube bright finish.
BD0700CS: 90o wall to wall horizontal grab bar with three anchoring points, made with AISI 304 stainless steel tube satin finish.
TUBING: made of stainless steel 32 mm diameter tube, seamless construction. The bending process guarantees the uniformity of the
diameter along the bends.
CONCEALED WALL BRACKET: three units made of stainless steel sheet, 3 mm thick and joined to the bar by welding to the ends of the
tube. It has three holes (BD2700 and BD2700B) or two holes (other references), with a diameter of 6.5 mm that allow the fixing of the bar
to the wall.
SNAP FLANGE COVER: three units that conceal the installation screws made of 1.5 mm thick polypropylene (BD2700 and BD2700B) or
0.8 mm thick stainless steel (other references).
Käterätikuivati on valmistatud messingist. (brass)
Полотенцесушители выполнены из латуни
Sobib nii küttevee kui ka tarbevee süsteemi.
Подходят как для отопительной системы, так и для ГВС
Maksimaalne töörõhk on 600 KPa
Максимальное рабочее давление 600 KPa
Maksimaalne temperatuur 85°C
максимальная температура 85°C
Võimalikud viimistlused Chroom +...%
Возможные покрытия Chroom +...%
Ref. 181020
|
TECHNICAL CHARACTERISTICS |
| Height | 465mm |
| Length | 455mm |
| Width | 700mm |
| Thickness | 1.2mm |
| Finish | 304 polished satin stainless steel |
Mezzo seebialus kroom LM
