Anti-corrosion treated steel.
Powder coated steel.
Discreet keyless locking system (push button inside).
Fixation in 4 points on the ground.
Easy opening by tilting the bowl forward.
Stirrups facilitate the insertion and removal of the bag.
Reduced opening to limit the introduction of bulky objects.
Special large capacity 100L
Compatible with trash bag 130 liters

Height 1013 mm
Width at front 578 mm
Depth to wall: 440 mm

• Toilet brush holder made of AISI 304 stainless steel, bright finish.

• Suitable for wall mounting or floor standing.

• Suitable for the hotel sector, for fitting in bath hotel rooms.

• Model suitable for public use.

• Handle made of AISI 304 stainless steel, 0.4 mm thick, bright finish.

• Cover made of AISI 304 stainless steel, 0.4 mm thick, bright finish.

• Inner rod made of AISI 304 stainless steel, 0.8 mm thick, bright finish.

• Brush made of sisal fiber.

• Screws and plugs for installation to the wall are provided.

600 x 600 x 130 mm
sensor with 950 ml soap bottle / ca. 750 paper towels

• Mirror cupboard with integrated sensor liquid soap dispenser and paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; visible surfaces satin finished and brushed.
• Crystal mirror with all round 2 mm chamfer and frosted window for optional lighting set.
• Sensor liquid soap dispenser with EWAR® eModule touch-free operated soap pump.
• Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
• Also refillable with large container using the plug-in tank as an option.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 750 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
• Accessible for refilling through lockable door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Lighting set available as an option.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, batteries, first fill with soap and one pack of paper towels.

• Weight (in kg): 19,8

350 x 580 x 210 mm
1 paper roll + 1 reserve roll

• Sensor paper roll dispenser with cabinet for reserve roll, battery-powered, in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed with tapered glossy surface at the bottom.
  Further available surfaces: see below.
• With touch-free operated, capacitive sensor technology, sensor distance approx. 3.5 cm.
  Paper length and idle time adjustable.
  Battery-powered with four standard 1.5 V Mono/LR20/12 A batteries.
• Designed for one paper roll and one reserve roll with dimensions: Width 215 mm, outer diameter max. 180 mm, inner diameter 50 mm.
• Inspection slot to indicate fill level, residual roll function allows a reserve roll to be inserted before residual roll is completely used up.
• Accessible for refilling through lockable door.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• Wear parts and front panels can be replaced as modules.
• Installation dimensions: 352 x 582 x 180 mm
• Mounting: With four screws in wall opening through fixing holes in the side walls.
• Delivery includes fixing material and first fill with one paper roll.

• Weight (in kg): 12,4
