298 x 1348 x 120 mm
ca. 250 paper towels / sensor with 950 ml soap bottle / 11 l

• Combination consisting of a sensor liquid soap dispenser, a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor liquid soap dispenser with EWAR® eModule touch-free operated soap pump.
• Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
• Also refillable with large container using the plug-in tank as an option.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 250 standard paper towels in zigzag fold.
  Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
• Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With eight screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, batteries, first fill with soap and one pack of paper towels.

• Weight (in kg): 15,8

Sama hinnaklassis on NL,OG,OL

Ø 38 x 208 mm
projection 130 mm

• Tabletop soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• Design height: 208 mm
  Outlet height: 198 mm
  Projection: 111 mm
• Non-drip soap pump with 500 ml soap bottle in plastics and pressure valve in stainless steel.
• Also available with 250 ml or 1000 ml containers in plastics.
• 500 ml container in stainless steel as an option for a surcharge.
• Designed for standard liquid soaps.
• Refillable from above by unscrewing the top part.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 22-26 mm, surface thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material.

• Weight (in kg): 1,6

Kirurgiline valamu Surgery S käsidosaatoritega L809mm

Tootekirjeldus :

Kirurgiline valamu Surgery S on loodud tagama ülimat hügieenitaset, pakkudes samas meeldivat ja kaasaegset disaini intensiivseks meditsiiniliseks kasutamiseks. Valamu elegantne ja kumer disain lihtsustab puhastamist ning roostevabast terasest käsidosaatorid lisavad kasutusmugavust. Puuduvad avatud ühenduskohad, mis vähendab bakterite leviku riski.

Komplekti kuulub:

1. Surgery S kirurgiline valamu
2. Käsidosaatorid (roostevaba teras) – 2 tk
3. Ruumisäästlik sifoon

Komplekti ei kuulu:

1. Segisti

Tehniline informatsioon:

• Seeria: Surgery
• Mõõdud (LxSxK): 809 x 599 x 938 mm
• Kaussi mõõdud (LxSxK): 809 x 590 x 240 mm
• Kuju: Kumer
• Paigaldustüüp: Seinapealne
• Kausside arv: 1
• Materjal: CreaCore (CC)
