Termostaadid, Vee Temperatuuriregulaatorid, Group Thermostatic Mixers
Termostaadid on seadmed, mis reguleerivad vee temperatuuri segistites või dušisegistites, tagades soovitud vee temperatuuri ning vältides ebameeldivaid temperatuurikõikumisi. Üks tüüp termostaate on grupitermostaatilised segistid, mis on mõeldud kasutamiseks mitme väljavooluga segistites, näiteks dušinurkades, vanni- ja dušikomplektides või muudes kohtades, kus on vaja reguleerida erinevate veevoolude temperatuure.
Group termostaatilised segistid on disainitud nii, et saaks reguleerida mitme väljavooluga segistite temperatuure ühe termostaadiga, mis võimaldab mugavat temperatuuri juhtimist kõigis väljavooludes üheaegselt. Näiteks võib see olla eriti mugav dušinurkades, kus on vaja reguleerida nii pea- kui ka käsiduši temperatuure ning hoida neid stabiilsena, et tagada meeldiv dušikogemus.
Group termostaatilised segistid võivad olla varustatud mitmesuguste funktsioonidega, nagu temperatuuri lukustamine, mälu funktsioon, temperatuuripiirangud jne. Need võivad olla valmistatud vastupidavatest materjalidest, nagu roostevaba teras, messing või messing-plastik kombinatsioon, tagades pikaajalise kasutuse.
Lisaks mugavusele ja funktsionaalsusele võivad group termostaatilised segistid pakkuda ka energiasäästlikke lahendusi, kuna need võivad aidata vähendada vee ja energiakulu, võimaldades täpset temperatuuri juhtimist ja vältides liigset vee raiskamist.
Kokkuvõtvalt võib öelda, et group termostaatilised segistid on spetsiaalsed termostaadid, mis on mõeldud mitme väljavooluga segistite temperatuuri reguleerimiseks, pakkudes mugavust, funktsionaalsust ja energiasäästlikkust. Need võivad olla valmistatud vastupidavatest materjalidest ja varustatud erinevate funktsioonidega, et vastata erinevatele kasutusvajadustele.
PREMIX COMFORT
Ref. 731005
Group thermostatic mixing valve for mixed water distribution from 32° to 42°C:
Anti-scalding safety.
Regulation of temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal cartridge with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with automotive cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C mini.
Pressure differences at the entrance: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring).
For bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
190 lpm - M1 1/2".
PREMIX COMFORT
Ref. 731500
Group thermostatic mixing valve for mixed water distribution from 32° to 42°C:
Anti-scalding safety.
Regulation of temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal cartridge with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with automotive cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C mini.
Pressure differences at the entrance: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring).
For bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
190 lpm - M1 1/2".
PREMIX SECURITY
Ref. 731055
Group thermostatic mixing valve for hot water circulating loops adjustable from 44°C to 58°C:
Anti-scalding safety.
Regulates temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal cartridge with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with thermostatic cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C mini.
Pressure differences at the entrance: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring) for bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
15% energy savings: optimised heat loss (comparison between a circulating loop at 55°C and a non-circulating system at 70°C).
Safety and prolongation of system life span (Hot water at >65°C leads to premature aging within the system).
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
190 lpm - M1 1/2".
PREMIX COMFORT
Ref. 731004
Group thermostatic mixing valve for mixed water distribution from 32° to 42°C:
Anti-scalding safety.
Regulation of temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal cartridge with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with automotive cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C mini.
Pressure differences at the entrance: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring).
For bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
140 lpm - M1 ¼".
PREMIX COMFORT
Ref. 731400
Group thermostatic mixing valve for mixed water distribution from 32° to 42°C:
Anti-scalding safety.
Regulation of temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal cartridge with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with automotive cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C mini.
Pressure differences at the entrance: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring).
For bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
140 lpm - M1 1/4".
PREMIX SECURITY
Ref. 731054
Group thermostatic mixing valve for hot water circulating loops adjustable from 44°C to 58°C:
Anti-scalding safety.
Regulates temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal shocks are possible.
Interchangeable cartridge with automotive cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C minimum.
Pressure differences at the inlets: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring) for bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
15% energy savings: optimised heat loss (comparison between a circulating loop at 55°C and a non-circulating system at 70°C).
Safety and prolongation of system life span (Hot water at >65°C leads to premature aging within the system).
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
140 lpm - M1 1/4 ".
PREMIX COMFORT
Ref. 731003
Group thermostatic mixing valve for mixed water distribution from 32° - 42°C:
Anti-scalding safety.
Regulates temperature variations.
Filters and non-return valves can be accessed from the outside without removing the mechanism.
Thermal shock with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with automotive cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C minimum.
Pressure difference at the inlets: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 - 10 bar (1 - 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring).
For bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
90 lpm - M1".
PREMIX COMFORT
Ref. 731300
Group thermostatic mixing valve for mixed water distribution from 32° to 42°C:
Anti-scalding safety.
Regulation of temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal cartridge with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with automotive cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C mini.
Pressure differences at the entrance: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring).
For bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
90 lpm - M1".
PREMIX SECURITY
Ref. 731053
Group thermostatic mixing valve for hot water circulating loops adjustable from 44°C to 58°C:
Anti-scalding safety.
Regulates temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal cartridge with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with thermostatic cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C mini.
Pressure differences at the entrance: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring) for bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
15% energy savings: optimised heat loss (comparison between a circulating loop at 55°C and a non-circulating system at 70°C).
Safety and prolongation of system life span (Hot water at >65°C leads to premature aging within the system).
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
90 lpm - M1".
PREMIX COMFORT
Ref. 731002
Group thermostatic mixing valve for mixed water distribution from 32° - 42°C:
Anti-scalding safety.
Regulates temperature variations.
Filters and non-return valves can be accessed from the outside without removing the mechanism.
Thermal shock with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with automotive cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C minimum.
Pressure difference at the inlets: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 - 10 bar (1 - 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring).
For bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
55 lpm - M3/4".
PREMIX COMFORT
Ref. 731200
Group thermostatic mixing valve for mixed water distribution from 32° to 42°C:
Anti-scalding safety.
Regulation of temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal cartridge with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with automotive cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C mini.
Pressure differences at the entrance: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring).
For bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
55 lpm - M 3/4".
PREMIX SECURITY
Ref. 731052
Group thermostatic mixing valve for hot water circulating loops adjustable from 44°C to 58°C:
Anti-scalding safety.
Regulates temperature variations.
Non-return valves and filters accessible from the exterior without having to remove the mechanism.
Thermal cartridge with no specific lever needed (push-button on the control knob).
Interchangeable cartridge with thermostatic cell.
High-resistance chrome-plated brass body.
Maximum hot water temperature: 85°C.
Differential hot water / mixed water: 15°C mini.
Pressure differences at the entrance: 1 bar maximum (0.5 bar recommended).
Minimum pressure / maximum: 1 to 10 bar (1 to 5 bar recommended).
Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring).
Mixed water outlet at the top (purple ring) for bottom outlet: unscrew / place lid at the top and outlet connector at the bottom.
15% energy savings: optimised heat loss (comparison between a circulating loop at 55°C and a non-circulating system at 70°C).
Safety and prolongation of system life span (Hot water at > 65°C leads to premature aging within the system).
Maximum temperature limiter, can be adjusted by the installer.
Reduced risk of scalding by limiting temperature at the point-of-use.
55 lpm - M3/4".
Angled isolating valve
Ref. 730804.2P
Ball valve with filter and testpoint (to connect pressureand temperature gauges).
Angled isolating valve
Ref. 730803.2P
Ball valve with filter and testpoint (to connect pressureand temperature gauges).
Angled isolating valve
Ref. 730802.2P
Ball valve with filter and testpoint (to connect pressureand temperature gauges).
PREMIX COMPACT
Ref. 733016
PREMIX COMPACT thermostatic mixing valve for mixed water distribution from 30 - 60°C:
For 2 to 7 sanitary points-of-use (depending on the flow rate).
Anti-scalding safety: immediate shut-off if cold or hot water supply fails.
Adjustable temperature from 30 - 60°C, can be blocked by the installer.
Brass body.
Filters and non-return valves.
Minimum flow rate to operate: 5 lpm.
Thermal shocks are possible.
M1/2".
Chrome-plated brass with blue control cap.
PREMIX COMPACT
Ref. 733021
PREMIX COMPACT thermostatic mixing valve for mixed water distribution from 30 - 60°C:
For 2 to 10 sanitary points-of-use (depending on the flow rate).
Anti-scalding safety: immediate shut-off if cold or hot water supply fails.
Adjustable temperature from 30 - 60°C, can be blocked by the installer.
Brass body.
Filters and non-return valves.
Minimum flow rate to operate: 5 lpm.
Thermal shocks are possible.
M3/4".
Chrome-plated brass with blue control cap.
PREMIX COMPACT
Ref. 733015
PREMIX COMPACT thermostatic mixing valve for mixed water distribution from 30 - 60°C:
For 2 to 7 sanitary points-of-use (depending on the flow rate).
Anti-scalding safety: immediate shut-off if cold or hot water supply fails.
Adjustable temperature from 30 - 60°C, can be blocked by the installer.
Brass body.
Filters and non-return valves.
Minimum flow rate to operate: 5 lpm.
Thermal shocks are possible.
M1/2".
Nickel-plated brass with blue control cap.
PREMIX COMPACT
Ref. 733020
PREMIX COMPACT thermostatic mixing valve for mixed water distribution from 30 - 60°C:
For 2 to 10 sanitary points-of-use (depending on the flow rate).
Anti-scalding safety: immediate shut-off if cold or hot water supply fails.
Adjustable temperature from 30 - 60°C, can be blocked by the installer.
Brass body.
Filters and non-return valves.
Minimum flow rate to operate: 5 lpm.
Thermal shocks are possible.
M3/4".
Nickel-plated brass with blue control cap.
PREMIX NANO thermostatic mixing valve
Ref. 732116
Hot water thermostatic mixing valve for mixed water distribution from 34 - 60°C:
For 1 - 2 taps or 1 shower.
Anti-scalding safety: immediate shut-off if cold or hot water fails.
Temperature pre-set at 38°C, can be adjusted by the installer from 34 - 60°C.
Brass body.
Filters and non-return valves.
Minimum flow rate to operate: 3 lpm.
Thermal shocks are possible.
Chrome-plated brass body M1/2'' inlets and Ø 15mm conical outlets.
PREMIX NANO thermostatic mixing valve
Ref. 732115
Hot water thermostatic mixing valve for mixed water distribution from 34 - 60°C:
For 1 - 2 taps or 1 shower.
Anti-scalding safety: immediate shut-off if cold or hot water fails.
Temperature pre-set at 38°C, can be adjusted by the installer from 34 - 60°C.
Brass body.
Filters and non-return valves.
Minimum flow rate to operate: 3 lpm.
Thermal shocks are possible.
Nickel-plated brass body M1/2'' inlets and Ø 15mm conical outlets.
PREMIX NANO thermostatic mixing valve
Ref. 732216
Hot water thermostatic mixing valve for mixed water distribution from 34 - 60°C:
For 1 to 2 taps or 1 shower.
Anti-scalding safety: automatic water shut-off in case of hot or cold water supply failure.
Temperature pre-set at 38°C, can be adjusted by the installer from 34 - 60°C.
Non-return valves and filters.
Minimum flow rate for operation: 3 lpm.
Thermal shocks are possible.
Polished chrome body, hot water inlet F3/8", cold water inlet M3/8"and mixed water outlet M3/8".
PREMIX NANO thermostatic mixing valve
Ref. 732016
Hot water thermostatic mixing valve for mixed water distribution from 34 - 60°C:
For 1 to 2 taps or 1 shower.
Anti-scalding safety: automatic water shut-off in case of hot or cold water supply failure.
Temperature pre-set at 38°C, can be adjusted by the installer from 34 - 60°C.
Non-return valves and filters.
Minimum flow rate for operation: 3 lpm.
Thermal shocks are possible.
Chrome-plated body, inlets F3/8" and outlet M3/8".
PREMIX NANO thermostatic mixing valve
Ref. 732012
Hot water thermostatic mixing valve for mixed water distribution from 34 - 60°C:
For 1 to 2 taps or 1 shower.
Anti-scalding safety: automatic water shut-off in case of hot or cold water supply failure.
Temperature pre-set at 38°C, can be adjusted by the installer from 34 - 60°C.
Non-return valves and filters.
Minimum flow rate for operation: 3 lpm.
Thermal shocks are possible.
Nickel-plated body, inlets F3/8" and outlet M3/8".
Connection kit
Ref. 732515
Connection kit 3/8" for PREMIX NANO 732216
Dušisegisti termostaat Oras Oramix 7261
- Kahva tüüp:Temperatuuriseadekahv, Veevooluhulga seadekahv, Temperatuuri turvapiiraja
- Mehaanilised osad: Tagasilöögiklapid, Prügipüüdur(id), Surveühtlustaja automaatseks temperatuuri seadmiseks
- Värv: Kroom
- Temperatuuri seaded:Turvapiiraja (38°C)
- Vooluhulk 300 kPa0.23 l/s
- Rõhukadu vooluhulgal (0.2 l/s)220 kPa
- Tagasivoolu kaitse (EN1717) EB
- Ühenduse mõõt: G3/4
- Kuum vesimax. +80°C
- Paigalduslaius: CC150± 3 mm
- Materjal: Messing
- Kasutussurve: 150 - 1000 kPa
- EN standard EN 1111
- HääleklassII (ISO 3822)
230,00 €
Isesulguv termostaadiga dušisegisti Idral 1/2"alla, 15sek
Self-closing thermostatic mixer for shower
- Chromed brass tap
- TMV3 thermostatic cartridge
- Non-return valves
372,10 €
Presto tervishoiu komplekt Sanifirst TOUCH MASTERMIX 75700 thermotaadiga dušisegisti
Tervishoiu kraanid ja segistid
> The Product Benefits
MASTERMIX PATENTED TECHNOLOGY
Innovative association of a specific ceramic cartridge and a thermostatic cartridge: safety and reliability. Without DHW/DCW cross-connection
Without check valve
Cold body: anti-scalding insulation
Body with a smooth interior: limits the risk of bacterial development (legionella, pseudomonas, etc.) Intuitive control units
Temperature limiter (41 ° C) and maximum flow rate stop limiter
Temperature maintenance and anti-scalding safety
Quick and easy assembly and maintenance
Secure thermal shock: accessible only by technical services
Eccentric fittings with 1/4 turn shut-off valves integrated into the product
Body with docking to the partition: optimized cleaning of all contact surfaces
> Anti-scalding safety
Temperature knob with temperature limiter at 41 ° C. Unlocking secured for thermal shock and accessible only by technical services without removing the knob.
> Anti-bacterial proliferation safety
Unique DHW and DCW no cross-connection system, produced by the association of a specific ceramic cartridge and a thermostatic cartridge compliant to NF EN 1111.
> Model
Shower mixer, downward outlet, wall mounted
Span 150 mm (+/-) 10 mm
Ceramic cartridge and thermostatic cartridge compliant to NF EN 1111
> Flow rate
Factory set to 9 L / min at 3 bar
Maximum flow rate adjustable to 6 - 9 - 12 L / min by the technical staff
> Recommended pressure
3 bar - avoid pressure differences greater than 1 bar between DHW and DCW. Minimum pressure: 1 bar.
Maximum pressure: 5 bar.
> Material
Chrome-plated zamak.
> Connection
Connection exclusively using a fixing plate with M G'1 / 2 connection 150 +/- 10mm span integrating shut-off valves, filtration and acoustic connection (supplied).
> Delivred with:
1-jet handshower ref 75279
wall support ref 75303
anti-stagnation connector ref 60568 smooth gray hose Lg 850 mm ref 75524
696,42 €
Termoregulaator paralleelse ühendusega 1/2"
Thermostatic mixing valve with internal temperature limiter Ref: 29006 - Thermostatic mixing valve with parallel 1/2'' inlets
-
> Flow:
maximum: 43 l/min at 3 bars minimum: 4 l/min at 3 bars
-
> Temperature :
Factory setting: 38°C
Temperature, hot water inlet: 85°C max
Minimum differential temperature: 15°C (Between hot water inlet and mixed outlet) Temperature control plan: 20 to 65°C at 3 bar
Mixed Temperature Stability: +/- 2°C from 37 to 42°C for a flow range from 12 to 47L/mn -
> Hydraulic supply :
G 1/2" (15x21) Inlet & Outlet
Red tag for hot water, and blue tag for cold water -
> Thermal resistance :
Designed to withstand thermal shocks at temperatures over 75°C during 30 min
-
> Security :
Anti-scald system: flow is immediately stopped if the cold water is cut off Internal temperature blocker
-
> Delivered with :
2 Filter gaskets
2 NF check valves Instruction manual -
> Standards & approvals :
200-hour neutral salt spray resistant (NSS) in accordance with ISO 9227 Brass body in accordance with EN 1982, EN 12164, EN 12156
152,00 €
Termoregulaator Presto 29002 kaitsega, 5 valamu või 3 duši, 60l/min 3 bar
Termoregulaator Presto 29003 kroomnupuga, 5 valamu või 3 duši, 45l/min 3 bar
498,17 €
Valamusegisti termostaadiga H205 L160 SECURITHERM Delabie H9726 kroom
SECURITHERM thermostatic basin mixer
Ref. H9726
Tall, single hole mixer with swivelling spout H. 205mm L. 150mm with smooth interior.
Spout with BIOSAFE hygienic outlet, suitable for fitting a BIOFIL filter.
Anti-scalding failsafe: shuts off immediately if the cold or hot water supply fails.
Scale-resistant thermostatic cartridge for temperature control.
¼-turn ceramic head for adjusting the flow rate.
Temperature can be adjusted, with two temperature limiters: first temperature limiter set at to 38°C (can be overridden), and second temperature limiter set at 41°C.
Thermal shocks are easy to undertake without removing the control knob or shutting off the cold water supply.
Flow rate regulated at 5 lpm.
ERGO control knobs.
Ergonomic pop-up waste, 11/4" in brass.
PEX flexibles F3/8" with filters and non-return valves.
Fixing reinforced via 2 stainless steel rods.
Thermostatic mixer ideal for healthcare facilities, retirement and care homes, hospitals and clinics.
Mixer suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
SECURITHERM thermostatic basin mixer
Ref. H9726| Connector | F3/8" |
| Technology | SECURITHERM thermostatic mixer |
| Height | 307mm |
| Drop height | 205mm |
| Spout length | 150mm |
| Flow rate | 5 lpm |
| Temperature limiter | Yes |
| Finish | Chrome-plated brass |
634,40 €
Valamusegisti termostaadiga H230 L200 SECURITHERM Delabie H9716 kroom
ECURITHERM thermostatic sink mixer
Ref. H9716
Tall, single hole mixer with swivelling tubular spout H. 225mm L.200mm with smooth interior.
Spout with hygienic flow straightener, suitable for fitting a BIOFIL terminal filter.
Anti-scalding failsafe: immediate shut-off if cold or hot water supply fails.
Scale-resistant thermostatic cartridge for adjusting the temperature.
¼-turn ceramic head for adjusting the flow rate.
Temperature can be adjusted, with two temperature limiters: first temperature limiter set at 38°C (can be overidden), and second temperature limiter set at 41°C.
Thermal shocks are easy to undertake without removing the control knob or shutting off the cold water.
Flow rate limited to 9 lpm at 3 bar.
ERGO control knobs.
PEX flexibles F3/8" with filters and non-return valves.
Fixing reinforced by 2 stainless steel rods.
Thermostatic mixer ideal for healthcare facilities, retirement and care homes, hospitals and clinics.
Suitable for people with reduced mobility.
TECHNICAL CHARACTERISTICS
SECURITHERM thermostatic sink mixer
Ref. H9716| Connector | F3/8" |
| Technology | SECURITHERM thermostatic mixer |
| Drop height | 225mm |
| Spout length | 200mm |
| Flow rate | 9 lpm at 3 bar |
| Temperature limiter | Yes |
| Finish | Chrome-plated brass |
573,40 €
Veesegamissõlm termostaat 1" kehaduššile Broen 17 513 009
Thermostatic Emergency Mixing Valve for body-, eye- and combi showers Fixed outlet temperature: 25°C / 77°F
Fail safe on hot and cold side:
Anti-scalding device on hot side
Thermostatic mixing valve, eye- and body shower, 28 mm comp.
