ADA kätekuivati uputatud
Width 11 13/16 Inches
Depth 6 Inches
Height 24 1/16 Inches
Opening Width 10 Inches
Opening Depth 6 Inches
Opening Height 9 7/8 Inches
Amps 4 - 4.4 Amps
Hertz 50 - 60
Phase 1
Voltage 208 - 240 Volts
Wattage 1,000 Watts
ADA Compliant Yes
Drying Time 17 Seconds
Finish Stainless Steel
Hands Free Yes
Installation Type Built-In
RPM 8,000
Style Heated

Contemporary design, ADA compliant recessed hand dryer. 6” deep drying alcove with a curved back and a ceramic water absorbent surface to capture and evaporate water. Type 304 satin-finish, stainless steel. Dryer delivers a 17-second dry time at a mere 70dBA and a sustainable power rating of 1.0kW

115V AC, 8.5 Amp., 50/60 Hz, 1000 Watts, Single Phase, cULus Listed.



208-240V AC, 4.0-4.4 Amp, 50/60 Hz, 1000 Watts, Single Phase, cULus Listed and CE marked.



Tootekood: BOB-3725 ,   Tarneaeg: 3 nädalad
1445,00 € (15%)
1700,00 €
Antivandaalne valamu + seebidosaator + termostaat + kätekuivati

AUM 026 INV is a stainless steel, partly wall-built in washbasin, containing the combination of a liquid soap dispenser, water tap and hand dryer in a small space. The washbasin is adjusted to be used also by wheelchair persons – it is shallow, completed with handles, the waste is hidden behind the wall. Controlled by durable piezo-pushbuttons, electronically controlled turn-off (the period of water running is settable by the owner). The washbasin is to be mounted through the wall, all technology components are behind the wall, and thus cannot be damaged by users (anti-vandal design).

A wall-hanged version may be supplied to order, or a version without any of the functions (e.g. onlz water plus soap, or water plus dryer). The washbasin is made of AISI 304 stainless steel. A recommended cleaning agent for stainless products maintenance: Würth – preservation (order no. 0893 121 K), cleaning (order no. 893 121 1).

Basic technical information
Power supply: 230 V, 50 Hz
IP protection: IP 55
Dimensions (visible from outside): 800 x 800 x 363 mm
Required thickness of wall: min. 100 mm
Outlet: d = 40 mm

Requirements for setting up the construction
  1. Opening in the wal 740 x 740 mm
  2. Prepared el. supply cable 3C x 1,5 s 230 V, 50 Hz
  3. Prepared water outlet according to technical scheme


Complete delivery
  • Stainless-steel washbasin with handles
  • Electronic hand dryer
  • Electronic soap dispenser
  • Electronic water tap
  • Through-wall frame with bolts
  • Waste with a stink trap
  • 230V / 12V source for the electronics

Tootekood: AZP-AUM 026.TV INV ,   Tarneaeg: 3-4 nädalad
2742,00 €
Desinfikatsiooni dosaator senasisene 950ml R/V teras satiin

DISINFECTANT DISPENSER WP 208-7

148 x 448 x 120 mm
950 ml tank

  • Disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
  • One-hand operated and non-drip disinfectant pump with 950 ml tank.
  • Tank with large, lockable refill opening.
  • Designed for standard disinfectants.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable, removable front panel with fall protection.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • Wear parts and front panel can be replaced as modules.
  • Installation dimensions: 150 x 450 x 110 mm
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material and first fill with soap.
  • Weight (in kg): 3,0
Tootekood: WAG-WP208-7S ,   Tarneaeg: 14 päeva
322,80 €
Desintfikatsiooni dosaator senasisene, kontaktivaba 950ml ,R/V teras satiin

SENSOR DISINFECTANT DISPENSER WP 208E-7

148 x 448 x 120 mm
950 ml tank

  • Sensor disinfectant dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
  • With EWAR® eModule touch-free operated disinfectant pump with 950 ml tank.
  • Tank with large, lockable refill opning.
  • Designed for standard disinfectants.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable, removable front panel with fall protection.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • eModule battery-powered with two 1.5 V Baby/LR14 batteries.
    Power supply available as an option.
  • Wear parts and front panel can be replaced as modules.
  • Installation dimensions: 150 x 450 x 110 mm
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material and batteries.
  • Weight (in kg): 3,4
Tootekood: WAG-WP208e-7S ,   Tarneaeg: 14 päeva
435,60 €
Kätepaberidosaator 250 lk+prügikast 11L uputav

COMBINATION PAPER TOWEL DISPENSER AND WASTE BIN WP 501

298 x 645 x 164 mm
ca. 250 paper towels / 11 l

  • Combination consisting of a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
  • Designed for approx. 250 standard paper towels in zigzag- or c-fold. Paper size (folded): 240-250 mm x 100-115 mm. Accessible for refilling through lockable front flap.
  • Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
  • Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
  • Wear parts and front panels can be replaced as modules.
  • Installation dimensions: 300 x 647 x 154 mm
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material and one pack of paper towels.
  • Weight (in kg): 8,5
Tootekood: WAG-WP501S ,   Tarneaeg: 14-21 päeva
623,00 €
Kätepaberidosaator 300-500 lk+Saniflow+prügikast 35,5L

Paper towel dispenser and Saniflow and Waste bin



This product range is especially designed to save space and provide solutions (2x1 and up to 3x1) with the possibility of providing three solutions in one body. Units designed to be recessed mounted or mounted on a surface that have a modern design and resistant materials, which are the best solution for locations that wish to be innovative.

The types of combined units provide:

Paper towel dispensers + Saniflow hand dryer® + bin

It is entirely welded, with a paper towel dispenser with riveted tray that prevents tearing the paper; accepts C and Z folded paper towels. Saniflow® automatic hand dryer and AISI 304 stainless steel bin, which is extractible so that it may be easily dumped. Optionally, a frame is available for installing on a surface.

Paper towel dispensers + paper bins

Several solutions are provided in this category depending on the type of paper used, rolls or towels, and the capacity of the bin, which ranges from 6.1 litres to 53 litres. The paper loads range between 200 towels and 800 towels in models C/Z and 200 mm in diameter in models that use paper rolls.
Tootekood: MDTES0040CS ,   Tarneaeg: 14-21 päeva
1554,00 €
Mähkimislaud, horisontaalne, R/V tears seinasisene
Tootekood: WAG-WP2010S ,   Tarneaeg: 4 nädalad
2001,60 €
Mähkimislaud, horisontaalne, R/V tears uputav
Tootekood: BOB-KB110-SSRE-IN ,   Tarneaeg: 4 nädalad
2218,00 €
Mähkimislaud, vertikaalne, R/V tears uputav
Tootekood: BOB-KB111-SSRE-IN ,   Tarneaeg: 4 nädalad
2218,00 €
Paberidosaator senasisene 250lk, R/V teras satiin

PAPER TOWEL DISPENSER WP 114

298 x 298 x 120 mm
ca. 250 paper towels

  • Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • With deep-drawn paper removal opening for easy paper removal.
  • Designed for approx. 250 standard paper towels in zigzag fold.
    Paper size (folded): 240-250 mm x 100-115 mm.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable front flap with fall protection.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • Wear parts can be replaced as modules.
  • Installation dimensions: 300 x 300 x 110 mm
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material and one pack of paper towels.
  • Weight (in kg): 3,7
Tootekood: WAG-WP114S ,   Tarneaeg: 14 päeva
287,00 €
Paberidosaator senasisene 500lk, R/V teras poleeritud

PAPER TOWEL DISPENSER WP 112

298 x 448 x 120 mm
ca. 500 paper towels

  • Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • With deep-drawn paper removal opening for easy paper removal.
  • Designed for approx. 500 standard paper towels in zigzag fold.
    Paper size (folded): 240-250 mm x 100-115 mm.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable front flap with fall protection.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • Wear parts can be replaced as modules.
  • Installation dimensions: 300 x 450 x 110 mm
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material and one pack of paper towels.
  • Weight (in kg): 4,8
Tootekood: WAG-WP112P ,   Tarneaeg: 14 päeva
360,00 €
Paberidosaator senasisene 500lk, R/V teras satiin

PAPER TOWEL DISPENSER WP 112

298 x 448 x 120 mm
ca. 500 paper towels

  • Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • With deep-drawn paper removal opening for easy paper removal.
  • Designed for approx. 500 standard paper towels in zigzag fold.
    Paper size (folded): 240-250 mm x 100-115 mm.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable front flap with fall protection.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • Wear parts can be replaced as modules.
  • Installation dimensions: 300 x 450 x 110 mm
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material and one pack of paper towels.
  • Weight (in kg): 4,8
Tootekood: WAG-WP112S ,   Tarneaeg: 14 päeva
318,00 €
Paberidosaator tööpinna alla, R/V teras satiin 250 lehte

PAPER TOWEL DISPENSER WP 166

298 x 148 x 164 mm
ca. 250 paper towels

  • Paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • With deep-drawn paper removal opening for easy paper removal.
  • Designed for approx. 250 standard paper towels in zigzag- or c-fold.
    Paper size (folded): 240-250 mm x 100-115 mm. Accessible for refilling through lockable front flap.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • Wear parts can be replaced as modules.
  • Installation dimensions: 300 x 150 mm
  • Mounting: With four screws on the inside, sideways.
  • Delivery includes fixing material and one pack of paper towels.
  • Weight (in kg): 3,1
Tootekood: WAG-WP166S ,   Tarneaeg: 14 päeva
198,55 € (5%)
209,00 €
Prügikast senasisene 11L, R/V teras satiin
 WASTE BIN WP 134

298 x 598 x 120 mm
11 l

  • Waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • Equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
  • Also suitable for use as a hygiene waste bin with the optional plastic hygiene bin WP34.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • Wear parts can be replaced as modules.
  • Installation dimensions: 300 x 600 x 110 mm
  • Mounting: With eight screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material.
  • Weight (in kg): 5,7
Tootekood: WAG-WP134S ,   Tarneaeg: 14 päeva
316,80 €
Prügikast senasisene 32L, R/V teras satiin


WASTE BIN WP 147

298 x 898 x 220 mm
32 l

  • Waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • Equipped with removable mesh basket. Capacity approx. 32 l. Accessible through front flap with fall protection.
  • Installation dimensions: 300 x 900 x 110 mm
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material.
  • Weight (in kg): 11,5

Tootekood: WAG-WP147S ,   Tarneaeg: 14 päeva
558,00 €
Sankotikandur uputav ,R/V teras satiin

SANITARY BAG DISPENSER FOR FLUSH-MOUNTING WP 256

148 x 148 x 50 mm
for 1 sanitary bag box

  • Sanitary bag dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304.
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • Designed for one standard sanitary bag box with dimensions of approx. 118 x 87 x 20 mm.
  • Accessible for refilling through lockable front flap.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • Wear parts can be replaced as modules.
  • Installation dimensions: 150 x 150 x 40 mm.
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material and first fill.
  • Weight (in kg): 0,8
Tootekood: WAG-WP256S ,   Tarneaeg: 14 päeva
187,00 €
Seebidosaator 950ml+Kätepaberidosaator 250 lk+prügikast 11L

COMBINATION PAPER TOWEL- AND SOAP DISPENSER 950ML BOTTLE AND WASTE BIN WP 500

298 x 1348 x 120 mm
ca. 250 paper towels / 950 ml soap bottle / 11 l

  • Combination consisting of a liquid soap dispenser, a paper towel dispenser and a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • Liquid soap dispenser with one-hand operated and non-drip soap pump.
  • Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
  • Also refillable with large container using the plug-in tank as an option.
  • Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
  • Designed for approx. 250 standard paper towels in zigzag fold.
    Paper size (folded): 240-250 mm x 100-115 mm.
  • Inspection slots to indicate fill level.
  • Accessible for refilling through lockable front flap with fall protection.
  • Waste bin equipped with removable mesh basket. Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
  • Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
  • Wear parts and front panels can be replaced as modules.
  • Installation dimensions: 300 x 1350 x 110 mm
  • Mounting: With eight screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material, first fill with soap and one pack of paper towels.
  • Weight (in kg): 15,4
Tootekood: WAG-WP500S ,   Tarneaeg: 14-21 päeva
1028,40 €
Seebidosaator kontaktivaba 950ml+Kätepaberidosaator 250 lk+prügikast 11L

COMBINATION PAPER TOWEL-, SENSOR - SOAP DISPENSER 950ML BOTTLE AND WASTE BIN WP 500E

298 x 1348 x 120 mm
ca. 250 paper towels / sensor with 950 ml soap bottle / 11 l



  • Combination consisting of a sensor liquid soap dispenser, paper towel dispenser and
    a waste bin in robust, germ-reducing and easy-care stainless steel (AISI 304).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • Sensor liquid soap dispenser with EWAR® eModule touch-free operated soap pump.
  • Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
  • Also refillable with large container using the plug-in tank as an option.
  • Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
  • Designed for approx. 250 standard paper towels in zigzag fold.
    Paper size (folded): 240-250 mm x 100-115 mm.
  • Inspection slots to indicate fill level.
  • Accessible for refilling through lockable front flap with fall protection.
  • Waste bin equipped with removable mesh basket.
    Capacity approx. 11 l. Accessible through lockable door with self-closing, flame-retardant disposal flap.
  • Keyed alike cylinder locks in corrosion-resistant zinc die-casting.
  • eModule battery-powered with two 1.5 V Baby/LR14 batteries.
    Power supply available as an option.
  • Wear parts and front panels can be replaced as modules.
  • Installation dimensions: 300 x 1350 x 110 mm
  • Mounting: With eight screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material, batteries, first fill with soap and one pack of paper towels.
  • Weight (in kg): 15,8
Tootekood: WAG-WP500e ,   Tarneaeg: 14-21 päeva
1141,00 €
Seebidosaator senasisene 1000ml , R/V teras satiin

LIQUID SOAP DISPENSER WP 106

148 x 148 x 120 mm
1000 ml soap tank

  • Liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • One-hand operated and non-drip soap pump with 1000 ml tank and pressure valve in brass.
  • Tank with large, lockable refill opening.
  • Designed for standard liquid soaps.
  • Accessible for refilling through lockable, removable front panel with fall protection.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • Wear parts can be replaced as modules.
  • Installation dimensions: 150 x 150 x 110 mm
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material.
  • Weight (in kg): 2,0



Tootekood: WAG-WP106S ,   Tarneaeg: 14 päeva
289,00 €
Seebidosaator senasisene 950ml R/V teras satiin

QUID SOAP DISPENSER WP 208

148 x 448 x 120 mm
950 ml bottle

  • Liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
    Further available surfaces: see below.
  • One-hand operated and non-drip soap pump.
  • Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
  • Also refillable with large container using the plug-in tank as an option.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable, removable front panel with fall protection.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • Wear parts and front panel can be replaced as modules.
  • Installation dimensions: 150 x 450 x 110 mm
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material and first fill with soap.
  • Weight (in kg): 4,0
Tootekood: WAG-WP208S ,   Tarneaeg: 14 päeva
309,60 €
Seebidosaator senasisene, kontaktivaba 950ml ,R/V teras satiin

SENSOR - LIQUID SOAP DISPENSER WP 208E

148 x 448 x 120 mm
950 ml bottle

  • Sensor liquid soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
  • All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed. Further available surfaces: see below.
  • With EWAR® eModule touch-free operated soap pump.
  • Designed for standard 950 ml disposable bottles of liquid soap or hand lotion.
  • Also refillable with large container using the plug-in tank as an option.
  • Inspection slot to indicate fill level.
  • Accessible for refilling through lockable, removable front panel with fall protection.
  • Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
  • eModule battery-powered with two 1.5 V Baby/LR14 batteries.
    Power supply available as an option.
  • Wear parts and front panel can be replaced as modules.
  • Installation dimensions: 150 x 450 x 110 mm
  • Mounting: With four screws in wall opening through fixing holes in the side walls.
  • Delivery includes fixing material, batteries and first fill with soap.
  • Weight (in kg): 4,4
Tootekood: WAG-WP208eS ,   Tarneaeg: 14 päeva
424,00 €
Süvistatud prügikast 2,5L RS1/B must mahuti

Süvistatav prügikast

süvistussügavus 150mm

Diameeter 380mm

Mahtuvus 2,5l/20-30 lehte

Koti mõõt 39x28CM

Nähtav osa :

Rõngas :poleeritud kroom, naturaalne messing.

harjatud kroom, harjatud R/V teras või 14 rinevat

värvitooni.

Mahuti materjal :värvitud PC/ABS

RS1/B Must Mahuti



Tootekood: QRS1/B ,   Tarneaeg: 2-4 nädalad
1246,00 €
Süvistatud prügikast 2,5L RS1/W valge mahuti

Süvistatav prügikast

süvistussügavus 150mm

Diameeter 380mm

Mahtuvus 2,5l/20-30 lehte

Koti mõõt 39x28CM

Nähtav osa :

Rõngas :poleeritud kroom, naturaalne messing.

harjatud kroom, harjatud R/V teras või 14 rinevat

värvitooni.

Mahuti materjal :värvitud PC/ABS

RS1/B Must Mahuti



Tootekood: QRS1/W ,   Tarneaeg: 2-4 nädalad
1246,00 €
Süvistatud sälvräti dosaator RS2/B must mahuti

Süvistatav paberidosator

süvistussügavus 150mm

Diameeter 286mm

Mahtuvus 80-100 lehte 85mmx205mm

Koti mõõt 39x28CM

Nähtav osa :

Rõngas :poleeritud kroom, naturaalne messing.

harjatud kroom, harjatud R/V teras või 14 rinevat

värvitooni.

Mahuti materjal :värvitud PC/ABS





Tootekood: QRS2/B ,   Tarneaeg: 2-4 nädalad
927,00 €
Süvistatud sälvräti dosaator RS2/W valge mahuti

Süvistatav paberidosator

süvistussügavus 150mm

Diameeter 286mm

Mahtuvus 80-100 lehte 85mmx205mm

Koti mõõt 39x28CM

Nähtav osa :

Rõngas :poleeritud kroom, naturaalne messing.

harjatud kroom, harjatud R/V teras või 14 rinevat

värvitooni.

Mahuti materjal :värvitud PC/ABS





Tootekood: QRS2/W ,   Tarneaeg: 2-4 nädalad
927,00 €
