WC roostevabast terasest

WC roostevabast terasest
Järjesta:
Kuva: Nimekirjana / Võrgustikuna

Aasia WC, R/V teras AISI 304

Tootekood: PPT ,   Tarneaeg: 7-21 päeva
420,00 €

AUZ 08 INV is a stainless-steel WC in matt design for the disabled. It is a stainless-steel toilet to stand on the floor at the wall. The drain is directed backwards (the bottom drain version AUZ 02 INV). The closet is based on the standard AUZ 08, which is heightened and lengthened to fulfil the directive regarding products for disabled persons. To increase the user comfort, the seating part is provided with a seat from hardened plastic. The closet includes a removable backrest recommended by the League for the rights of the wheelchair bound.



The standing WC is suitable for places where the common closet cannot be attached to the side wall, because of a thin bearing particle, for example.



It is suitable to supplement the closet with an automatic pressure-water flushing device with delayed flushing AUZ 3 INV (suitable for the disabled) or any flushing device with a cistern.

Basic technical information
Water inlet: d= 34 - 50 mm
Min. water flow: 70 l/min
Outlet: d= 90 mm
Weight: 27 kg

Complete delivery
  • Stainless steel closet
  • Plastic seat
  • Anchoring material
  • Stainless-steel backrest
Tootekood: AZP-AUZ 08 INV ,   Tarneaeg: 3-4 nädalad
1890,00 €



AUZ 08

stainless-steel standing closet, with hardened seat, back drain






AUZ 08 is a stainless-steel WC in matt design. To increase the user comfort, it is provided with a grey seat with a lid made of hardened plastic (newly also with a seat in black design AUZ 08.CS). AUZ 08 is designed to stand on the floor at the wall; it is suitable for places where the common closet cannot be attached to the wall, because of a thin bearing particle, for example. The standard version of AUZ 08 has a back drain (the version with the bottom drain AUZ 02). It is suitable to supplement the WC with the automatic pressure water flushing device AUZ 3, automatic flushing device with the piezo button AUZ 3.P (or the vandal-resistant flushing device BSAZ 01) or any flushing device with a cistern.



Thanks to its resistance to damage, the closet is primarily intended for social facilities with demanding operation, such as highway lay-byes, alehouses, etc., where easy maintenance of sanitary conditions is required. WC is also manufactured in the design for the disabled under the designation AUZ 08 INV



Further closet versions can be found in the section Stainless-steel closets or Stainless-steel safety closets.




Basic technical information
Water inlet: d= 34-50 mm
Min. water flow: 70 l/min
Outlet: d= 90 mm
Weight: 23 kg


Requirements for setting up the construction
  1. Set-up outlet d = 110 mm including rubber sleeve for pipe d = 90 mm.
  2. Set-up water inlet d= 34-50 mm according to chosen sealing.


Complete delivery
  • Stainless steel closet
  • Plastic seat
  • Anchoring material


Made to order
  • AUZ 3 - automatic pressure flushing system
  • AUZ 3.P - automatic pressure flushing system with piezo control
  • BSAZ 01 - vandal resistant pressure flushing system

Tootekood: AZP-AUZ 08 ,   Tarneaeg: 3-4 nädalad
1722,00 €

R/V teras WC pott ja valamu

AISI304 paksus 1,5 mm

Kinnitus poltidega läbi seina

Loputus ühendus 1"

WC äravool 100mm

Valamu ärravool 32mm



NB! Vee mehhanismid on vaja tellida eraldi



Tootekood: PCOMP-TP ,   Tarneaeg: 6-7 nädalad
2500,00 €

R/V teras WC pott ja valamu

AISI304 paksus 1,5 mm

Kinnitus poltidega läbi seina

Loputus ühendus 1"

WC äravool 100mm

Valamu ärravool 32mm



NB! Vee mehhanismid on vaja tellida eraldi



Tootekood: PCOMP-003TS ,   Tarneaeg: 6-7 nädalad
2500,00 €

R/V teras WC pott ja valamu

AISI304 paksus 1,5 mm

Kinnitus poltidega läbi seina

Loputus ühendus 1"

WC äravool 100mm

Valamu ärravool 32mm



NB! Vee mehhanismid on vaja tellida eraldi



Tootekood: PCOMP-TV ,   Tarneaeg: 6-7 nädalad
2500,00 €

Combi KOMPACT HW/CW - washbasin and floor-standing WC pan
Ref. 161700

Combination unit: washbasin and floor-standing left hand WC pan with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sides and 1 on the top, with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproof push-button and anti-blocking system, 7-second time flow, M½".
Available with 2 buttons cold water/mixed water.
WC equipped with time flow flush valve, 7-second time flow, M¾".
Water inlet: washbasin M½", WC M¾".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin trap.
Easy to install: only one water outlet for both washbasin and WC, water inlet and outlet already connected.
Weight: 36kg.



TECHNICAL FEATURES

Combi KOMPACT HW/CW - washbasin and floor-standing WC pan
Ref. 161700

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-161700 ,   Tarneaeg: 4-6 nädalad
3528,00 €

Combi KOMPACT HW/CW - washbasin and floor-standing WC pan
Ref. 161800

Combination unit: washbasin and floor-standing central WC pan with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sides and 1 on the top, with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproof push-button and anti-blocking system, 7-second time flow, M½".
Available with 2 buttons cold water/mixed water.
WC equipped with time flow flush valve, 7-second time flow, M¾".
Water inlet: washbasin M½", WC M¾".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin trap.
Easy to install: only one water outlet for both washbasin and WC, water inlet and outlet already connected.
Weight: 36kg.



TECHNICAL FEATURES

Combi KOMPACT HW/CW - washbasin and floor-standing WC pan
Ref. 161800

Height 1000mm
Length 850mm
Width 400mm
Thickness 2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-161800 ,   Tarneaeg: 4-6 nädalad
3528,00 €

Combi KOMPACT HW/CW - washbasin and floor-standing WC pan
Ref. 161600

Combination unit: washbasin and floor-standing right hand WC pan with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sides and 1 on the top, with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproof push-button and anti-blocking system, 7-second time flow, M½".
Available with 2 buttons cold water/mixed water.
WC equipped with time flow flush valve, 7-second time flow, M¾".
Water inlet: washbasin M½", WC M¾".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin trap.
Easy to install: only one water outlet for both washbasin and WC, water inlet and outlet already connected.
Weight: 36kg.



TECHNICAL FEATURES

Combi KOMPACT HW/CW - washbasin and floor-standing WC pan
Ref. 161600

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-161600 ,   Tarneaeg: 4-6 nädalad
3528,00 €

KOMPACT washbasin and floor-standing WC combination
Ref. 160700

Combination unit: washbasin and floor-standing WC pan on left sidewith recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sidesand 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.
[Formerly ref: 0610030007]



TECHNICAL FEATURES

KOMPACT washbasin and floor-standing WC combination
Ref. 160700

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel
Tootekood: DE-160700 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT washbasin and wall-hung WC combination
Ref. 160400

Combination unit: washbasin and suspended WC pan on left side with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sidesand 1 on the top with theft prevention TORX security screws.Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.
[Formerly ref: 0610030004]

TECHNICAL FEATURES

KOMPACT washbasin and wall-hung WC combination
Ref. 160400

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel



Tootekood: DE-160400 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT washbasin and floor-standing WC combination
Ref. 160800

Combination unit: washbasin and floor-standing central WC panwith recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sidesand 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
WC pan central to the unit.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.
[Formerly ref: 0610030008]



TECHNICAL FEATURES

KOMPACT washbasin and floor-standing WC combination
Ref. 160800

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel
Tootekood: DE-160800 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT washbasin and wall-hung WC combination
Ref. 160300

Combination unit: washbasin and suspended WC pan on right side with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sidesand 1 on the top with theft prevention TORX security screws.Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.
[Formerly ref: 0610030003]



TECHNICAL FEATURES

KOMPACT washbasin and wall-hung WC combination
Ref. 160300

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel
Tootekood: DE-160300 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT washbasin and floor-standing WC combination
Ref. 160600

Combination unit: washbasin and floor-standing WC pan on right side with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sidesand 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.
[Formerly ref: 0610030006]



TECHNICAL FEATURES

KOMPACT washbasin and floor-standing WC combination
Ref. 160600

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel
Tootekood: DE-160600 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT washbasin and wall-hung WC combination
Ref. 162400

Washbasin combination unit with cistern, mounted WC pan on left side with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sides and 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel body thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface is easy to clean.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproof push-button and anti-blocking system, 7 second time flow, M1/2".
WC fitted with 6-litre cistern.
Water inlets: washbasin M1/2", WC M3/8".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.



TECHNICAL FEATURES

KOMPACT washbasin and wall-hung WC combination
Ref. 162400

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-162400 ,   Tarneaeg: 4-6 nädalad
3846,00 €

KOMPACT washbasin and floor-standing WC combination
Ref. 162700

Washbasin combination unit with cistern, floor-standing WC pan on left side with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sides and 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel body thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface is easy to clean.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproof push-button and anti-blocking system, 7 second time flow, M1/2".
WC fitted with 6-litre cistern.
Water inlets: washbasin M1/2", WC M3/8".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.

TECHNICAL FEATURES

KOMPACT washbasin and floor-standing WC combination
Ref. 162700

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-162700 ,   Tarneaeg: 4-6 nädalad
3846,00 €

KOMPACT washbasin and wall-hung WC combination
Ref. 162500

Washbasin combination unit with cistern, mounted WC pan in centre with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sides and 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel body thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface is easy to clean.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproof push-button and anti-blocking system, 7 second time flow, M1/2".
WC fitted with 6-litre cistern.
Water inlets: washbasin M1/2", WC M3/8".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.



TECHNICAL FEATURES

KOMPACT washbasin and wall-hung WC combination
Ref. 162500

Height 1000mm
Length 850mm
Width 400mm
Thickness 2mm
Finish Polished satin 304 stainless steel

Tootekood: DE-162500 ,   Tarneaeg: 4-6 nädalad
3846,00 €

KOMPACT washbasin and floor-standing WC combination
Ref. 162800

Washbasin combination unit with cistern, floor-standing WC pan in centre with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sides and 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel body thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface is easy to clean.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproof push-button and anti-blocking system, 7 second time flow, M1/2".
WC fitted with 6-litre cistern.
Water inlets: washbasin M1/2", WC M3/8".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.



TECHNICAL FEATURES

KOMPACT washbasin and floor-standing WC combination
Ref. 162800

Height 1000mm
Length 850mm
Width 400mm
Thickness 2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-162800 ,   Tarneaeg: 4-6 nädalad
3846,00 €

KOMPACT washbasin and floor-standing WC combination
Ref. 162600

Washbasin combination unit with cistern, floor-standing WC pan on right side with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sides and 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel body thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface is easy to clean.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproof push-button and anti-blocking system, 7 second time flow, M1/2".
WC fitted with 6-litre cistern.
Water inlets: washbasin M1/2", WC M3/8".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.

TECHNICAL FEATURES

KOMPACT washbasin and floor-standing WC combination
Ref. 162600

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-162600 ,   Tarneaeg: 4-6 nädalad
3846,00 €

KOMPACT TC washbasin and wall-hung WC combination
Ref. 166400

Combination unit: washbasin and suspended WC pan on left sidewith recessed toilet roll holder.
Service duct installation (through-the-wall).
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
Left hand WC pan
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
200mm threaded rod can be cut to size (other lengths available on demand).
Weight: 30kg.
[Formerly ref: 0616130004]



Technical features

KOMPACT TC washbasin and wall-hung WC combination
Ref. 166400

Height 1000mm
Length 615mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel


Tootekood: DE-166400 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT TC washbasin and floor-standing WC combination
Ref. 166700

Combination unit: washbasin and floor-standing WC pan on left sidewith recessed toilet roll holder.
Service duct installation (through-the-wall).
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
200mm threaded rod can be cut to size (other lengths available on demand).
Weight: 30kg.
[Formerly ref: 0616130007]



TECHNICAL FEATURES

KOMPACT TC washbasin and floor-standing WC combination
Ref. 166700

Height 1000mm
Length 615mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel
Tootekood: DE-166700 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT TC washbasin and wall-hung WC combination
Ref. 166500

Combination unit: washbasin and WC pan suspended centrallywith recessed toilet roll holder.
Service duct installation (through-the-wall).
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
Central WC pan
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm
200mm threaded rod can be cut to size (other lengths available on demand).
Weight: 30kg.
[Formerly ref: 0616130005]



TECHNICAL FEATURES

KOMPACT TC washbasin and wall-hung WC combination
Ref. 166500

Height 1000mm
Length 615mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel
Tootekood: DE-166500 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT TC washbasin and floor-standing WC combination
Ref. 166800

Combination unit: washbasin and floor-standing central WC panwith recessed toilet roll holder.
Service duct installation (through-the-wall).
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproof push-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
200mm threaded rod can be cut to size (other lengths available on demand).
Weight: 30kg.
[Formerly ref: 0616130008]

TECHNICAL FEATURES

KOMPACT TC washbasin and floor-standing WC combination
Ref. 166800

Height 1000mm
Length 615mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel
Tootekood: DE-166800 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT TC washbasin and floor-standing WC combination
Ref. 166600

Combination unit: washbasin and floor-standing WC pan on right sidewith recessed toilet roll holder.
Service duct installation (through-the-wall).
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm
200mm threaded rod can be cut to size (other lengths available on demand).
Weight: 30kg.
[Formerly ref: 0616130006]



Technical features

KOMPACT TC washbasin and floor-standing WC combination
Ref. 166600

Height 1000mm
Length 615mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel
Tootekood: DE-166600 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT TC washbasin and wall-hung WC combination
Ref. 166300

Combination unit: washbasin and suspended WC pan on right sidewith recessed toilet roll holder.
Wall-mounted with cross wall installation via a service duct.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlets: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm.
200mm threaded rod can be cut to size (other lengths available on demand).
Weight: 30kg.
[Formerly ref: 0616130003]



TECHNICAL FEATURES

KOMPACT TC washbasin and wall-hung WC combination
Ref. 166300

Height 1000mm
Length 615mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel
Tootekood: DE-166300 ,   Tarneaeg: 4-6 nädalad
3396,00 €

KOMPACT washbasin and wall-hung WC combination
Ref. 162300

Washbasin combination unit with cistern, mounted WC pan on right side with recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sidesand 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel body thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface is easy to clean.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws: makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproof push-button and anti-blocking system, 7 second time flow, M1/2".
WC fitted with 6-litre cistern.
Water inlets: washbasin M1/2", WC M3/8".
Recessed horizontal water outlet: Ø 100mm.
Supplied with washbasin siphon.
Easy to install: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg.



TECHNICAL FEATURES

KOMPACT washbasin and wall-hung WC combination
Ref. 162300

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-162300 ,   Tarneaeg: 4-6 nädalad
3846,00 €

KOMPACT washbasin and wall-hung WC combination
Ref. 160500

Combination unit: washbasin and WC pan suspended centrallywith recessed toilet roll holder.
Wall-mounted installation with 3 access panels, 2 on the sidesand 1 on the top with theft prevention TORX security screws.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel unit thickness: 2mm.
Rounded corners and edges for improved safety.
Smooth surface for easy cleaning.
Suitable for prisons, police stations, etc.
WC pan is completely welded to washbasin, no screws:
makes cleaning easier and prevents concealment of objects.
Washbasin equipped with time flow tap: stainless steel tamperproofpush-button and anti-blocking system, 7 second time flow, M1/2".
WC equipped with time flow flush valve, 7 second time flow, M3/4".
Water inlet: washbasin M1/2", WC M3/4".
Recessed horizontal water outlet: Ø 100mm
Supplied with washbasin siphon.
Easy installation: only one water outlet for both washbasin and WC,water inlet and outlet already connected.
Weight: 36kg
[Formerly ref: 0610030005]



TECHNICAL FEATURES

KOMPACT washbasin and wall-hung WC combination
Ref. 160500

Height 1000mm
Length 735mm
Width 725mm
Thickness 2mm
Finish 304 polished satin stainless steel
Tootekood: DE-160500 ,   Tarneaeg: 4-6 nädalad
3396,00 €

SHA XS squat WC pan
Ref. 113720

Floor-recessed squat WC pan, 500 x 325 x 600mm.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness 1.2mm.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
Bowl shape suitable for male and female use.
Non-slip foot area.
Vertical waste outlet: Ø 100mm.
Flushing system with one 304 stainless steel spreader.
Supplied with stainless steel trap welded to squat WC pan.
Weight: 7kg.

TECHNICAL FEATURES

SHA XS squat WC pan
Ref. 113720

Height 30mm
Depth 325mm
Length 600mm
Width 500mm
Thickness 1.2mm
Finish 304 polished satin stainless steel
Tootekood: DE-113720 ,   Tarneaeg: 4-6 nädalad
669,00 €

SHA 700 squat WC pan
Ref. 113610

Floor-recessed squat WC pan, 700 x 220 x 700mm.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness 1.2mm.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
Bowl shape suitable for male and female use.
Non-slip foot area.
Vertical waste outlet: Ø 100mm.
Flushing system with one 304 stainless steel spreader.
Weight: 6kg.10-year warranty.



TECHNICAL FEATURES

SHA 700 squat WC pan
Ref. 113610

Height 30mm
Depth 220mm
Length 700mm
Width 700mm
Thickness 1.2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-113610 ,   Tarneaeg: 4-6 nädalad
546,00 €

SHA XS squat WC pan
Ref. 113710

Floor-recessed squat WC pan, 500 x 220 x 600mm.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness 1.2mm.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
Bowl shape suitable for male and female use.
Non-slip foot area.
Vertical waste outlet: Ø 100mm.
Flushing system with one 304 stainless steel spreader.
Weight: 5kg.



TECHNICAL FEATURES

SHA XS squat WC pan
Ref. 113710

Height 30mm
Depth 220mm
Length 600mm
Width 500mm
Thickness 1.2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-113710 ,   Tarneaeg: 4-6 nädalad
450,00 €

SHA 700 squat WC pan
Ref. 113620

Floor-recessed squat WC pan, 700 x 345 x 700mm.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness 1.2mm.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
Bowl shape suitable for male and female use.
Non-slip foot area.
Vertical waste outlet: Ø 100mm.
Flushing system with one 304 stainless steel spreader.
Supplied with stainless steel trap welded to squat WC pan.
Weight: 8kg.
10-year warranty.

[Formerly ref: 0113630020]

TECHNICAL FEATURES

SHA 700 squat WC pan
Ref. 113620

Height 30mm
Depth 345mm
Length 700mm
Width 700mm
Thickness 1.2mm
Finish Polished satin 304 stainless steel
Tootekood: DE-113620 ,   Tarneaeg: 4-6 nädalad
774,00 €

Delabie süvistatav dual control electronic battery-operated WC ventiil RST

TEMPOMATIC dual control plate for WCs

Ref. 464006

TEMPOMATIC recessed, dual control, electronic valve for direct flush, kit 2/2:
Flush system without cistern: directly connected to pipework.
Battery-operated with CR123 6V Lithium batteries.
Satin finish stainless steel wall plate 186 x 186mm and chrome-plated metal button, with integrated electronics.
TEMPOMATIC F¾" flush valve is compatible with sea water, rain water and grey water.
Shock-resistant infrared presence detection sensor.
Detection delay is 10 seconds.
Voluntary activation (anti-blocking push-button) or automatically without contact when the user leaves.
Independent push-button: the flush will activate even if the power supply fails.
"Intelligent" automatic rinsing: flush volume adapts according to use - 3L "short" usage, 6L "long" usage - (can be adjusted to 2L/4L or 5L/9L).
3 programmes (rinsing volume can be set according to type of WC pan).
Hygienic duty flush every 24 hours (can be adjusted to 12 hours or OFF) after the last use.
Base flow rate: 1L/sec at 1 bar dynamic pressure.
Suitable for rimless WC pans without flow rate regulation and suitable for people with reduced mobility.


Order with frame system references 564060DE or 564065DE, or with recessed housing 464PBOX.


TECHNICAL CHARACTERISTICS

TEMPOMATIC dual control plate for WCs

Ref. 464006
Supply 6V batteries
Connector F¾"
Technology Electronic and time flow
Length 186mm
Width 186mm
Finish Satin stainless steel
Tootekood: DE-464006 ,   Tarneaeg: 14-21 päeva
672,00 €

Delabie TEMPOMATIC WC ventiil 3/4" seina süvistav baas 6V bat kit 1/2 (liskas on vaja DE-464006)



Recessed waterproof housing for TEMPOMATIC dual control WC

Ref. 464PBOX

Recessed waterproof housing, kit 1/2:
Flush system without cistern: directly connected to pipework.
Compatible with electronic WC valve.
CR123 6V Lithium battery-operated.
Collar with waterproof seal.
Hydraulic connection to the outside and maintenance from the front.
Adjusts to all types of installation (rails, solid walls, panels).
Compatible with wall finishes from 10 - 120mm (while maintaining the minimum recessing depth of 93mm).
Suitable for standard or "pipe-in-pipe" supply.
Stopcock and flow rate adjustment, activation and electronic unit are all integrated and accessible from the front.
Backflow prevention device inside the housing.
Secure system flush without sensitive elements.
Outlet connection for PVC tube Ø26/32mm.


Order with control-plate reference 464006.


TECHNICAL CHARACTERISTICS

Recessed waterproof housing for TEMPOMATIC dual control WC

Ref. 464PBOX
Connector F¾"
Technology Electronic and time flow
Height 150mm
Depth 93 to 190mm
Width 225mm





Tootekood: DE-464PBOX ,   Tarneaeg: 14-21 päeva
213,00 €

700 S TC wall-hung WC pan
Ref. 160710

Wall-hung WC pan with cross wall installation for service ducts.
700mm elongated pan for improved comfort for people with reduced mobility (700 S TC).
Elegant and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm.
One-piece, pressed WC bowl, seam-free for easy maintenance and better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm.
Horizontal waste outlet: Ø 100mm.
Water saving: works with 4L or more of water.
200mm threaded rod can be cut to size (other lengths available on request).
Shrouded WC pan.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 16.5kg.



TECHNICAL FEATURES

700 S TC wall-hung WC pan
Ref. 160710

Height 350mm
Length 700mm
Width 360mm
Thickness 1.5mm
Finish Polished satin 304 stainless steel
Tootekood: DE-160710 ,   Tarneaeg: 14-21 päeva
1608,00 €

S21 P TC floor-standing WC pan
Ref. 160550

Floor-standing WC pan with through-the-wall installation for service ducts.
Elegant and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm
One-piece, pressed WC bowl, seam-free for easy maintenanceand better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm
Horizontal waste outlet: Ø 100mm
Water saving: works with 4L or more of water.
200mm threaded rod can be cut to size (other lengths available on request).
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 13.5kg.
[Formerly ref: 0116550001]



TECHNICAL FEATURES

S21 P TC floor-standing WC pan
Ref. 160550

Height 400mm
Length 580mm
Width 360mm
Thickness 1.5mm
Finish 304 polished satin stainless steel
Tootekood: DE-160550 ,   Tarneaeg: 14-21 päeva
1350,00 €

S21 S TC wall-hung WC pan
Ref. 160310

Wall-hung WC pan with through-the-wall installation for service ducts.
Elegant and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm
One-piece pressed WC bowl, seam-free for easy maintenanceand better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm
Horizontal waste outlet: Ø 100mm
Water saving: works with 4L or more of water.
200mm threaded rod can be cut to size (other lengths are available on request).
Shrouded WC pan.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 11kg.
[Formerly ref: 0116320001]



TECHNICAL FEATURES

S21 S TC wall-hung WC pan
Ref. 160310

Height 350mm
Length 535mm
Width 360mm
Thickness 1.5mm
Finish 304 polished satin stainless steel





Tootekood: DE-160310 ,   Tarneaeg: 14-21 päeva
1284,00 €

DESCRIPTION

MONOBLOCO 700 PMR WC pan with cistern
Ref. 110790

Floor-standing WC pan with dual flush cistern 3L/6L, 370 x 895 x 700mm.
700mm elongated pan for better comfort for people with reduced mobility.
Bacteriostatic 304 stainless steel. Polished satin finish.
Stainless steel thickness: 1.5mm.
One-piece pressed WC bowl, seam-free for better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim. Water supply can be recessed from below or exposed from the side (right/left).
Recessed horizontal or vertical waste outlet. Supplied with PVC pipe.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick to install: 2 access panels with theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 22kg.
10-year warranty.

TECHNICAL FEATURES

MONOBLOCO 700 PMR WC pan with cistern
Ref. 110790

Height 895mm
Length 700mm
Width 370mm
Thickness 1.5mm
Finish Polished satin 304 stainless steel


Tootekood: DE-110790 ,   Tarneaeg: 7 nädalad
1986,00 €

DESCRIPTION

TEMPOFIX 3 self-supporting frame system with electronic WC valve

Ref. 564005-464000

Provisional availability 1st half
2021

Please contact the sales office to check availability.
Self-supporting frame system for wall-hung WCs:
- Black powder-coated steel frame.
- Fixes to load-bearing floors.
- Frame height can be adjusted from 0 - 200mm (with 1m mark).
- Ø 32mm flush tube with Ø 55mm connection washer.
- PVC soil pipe, Ø 100mm outlet to be glued to waterproof seal, with 2 setting positions.
- Delivered pre-mounted.
- Compatible with solid walls from 10 - 120mm.
- 10-year warranty.

Fitted with a TEMPOMATIC dual control F¾" electronic direct flush valve:
- 230/6V mains supply (cable and transformer supplied).
- Satin finish stainless steel wall plate 186 x 186mm and chrome-plated metal button with integrated electronics.
- Waterproof recessing housing.
- Detection delay is 10 seconds.
- Voluntary activation (push-button with anti-blocking) or automatically when the user leaves.
- "Intelligent" automatic rinsing (flush volume adapts according to use).
- 3 programmes (rinsing volume can be set according to type of WC pan).
- Hygienic duty flush, every 24 hours (can be adjusted to 12 hours or OFF) after the last use.
- Backflow prevention device inside the housing.
- Integrated stopcock and flow rate adjuster.
- Compatible with sea water and grey water.

Technical characteristics: see TEMPOMATIC dual control ref. 464SBOX-464000.

Kit contents:
(564005): frame system, soil pipe Ø 100mm, flush tube, recessed housing with cover, valve configured for system flush, vacuum breaker, stopcock, connection accessories.
(464000): control plate, transformer, collar for waterproofing, solenoid valve, cartridge.


TECHNICAL CHARACTERISTICS

TEMPOFIX 3 self-supporting frame system with electronic WC valve

Ref. 564005-464000
Supply Mains supply 230/6V
Connector ¾"
Technology Electronic and time flow
Height 1000 - 1320mm
Depth 177mm
Width 350mm
Finish Satin finish stainless steel
Tootekood: DE-564005-464000 ,   Tarneaeg: 14-21 päeva
1278,00 €

Portinox WC pott loputuskastiga, ja istmega

Tootekood: PINP-655-OVC-TB-P+PWC Mahagon ,   Tarneaeg: 8 nädalad
1920,00 €
Tootekood: PINS-535-OVC + PWC-Wood mahagon ,   Tarneaeg: 8 nädalad
1440,00 €

DESCRIPTION

MONOBLOCO S21 WC pan with cistern
Ref. 110390

Floor-standing WC pan with dual flush cistern 3L/6L, 370 x 815 x 620mm.
Bacteriostatic 304 stainless steel. Polished satin finish.
Stainless steel thickness: 1.5mm.
One-piece pressed WC bowl, seam-free for better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim. Water supply can be recessed from below or exposed from the side (right/left).
Recessed horizontal or vertical waste outlet. Supplied with PVC pipe.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick to install: 2 access panels with theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 21kg.
10-year warranty.



TECHNICAL FEATURES

MONOBLOCO S21 WC pan with cistern
Ref. 110390

Height 815mm
Length 620mm
Width 370mm
Thickness 1.5mm
Finish 304 polished satin stainless steel
Tootekood: DE-110390 ,   Tarneaeg: 7 nädalad
1872,00 €

700 P floor-standing WC pan
Ref. 110700

Floor-standing WC pan, 360 x 480 x 700mm.
700mm elongated pan for better comfort for people with reduced mobility.
Elegant and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm.
One-piece pressed WC bowl, seam-free for easy maintenanceand better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm.
Horizontal waste outlet: Ø 100mm. Supplied with PVC pipe.
Water saving: works with 4L or more of water.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick and easy to install: 2 access panels with theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 15kg.

Tootekood: DE-110700 ,   Tarneaeg: 14-21 päeva
1615,00 €

BCN P floor-standing stainless steel pan
Ref. 110100

Floor-standing WC pan, 360 x 400 x 580mm.
Elegant and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm.
Horizontal or vertical waste outlet: Ø 100mm. Supplied with PVC pipe.
Water saving: works with 4L or more of water.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick and easy to install: 2 access panels with theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 12kg.

Tootekood: DE-110100 ,   Tarneaeg: 14-21 päeva
1284,00 €

S21 P floor-standing WC pan
Ref. 110300

Floor-standing WC pan, 360 x 400 x 580mm.
Elegant and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm.
Horizontal waste outlet: Ø 100mm. Supplied with PVC pipe.
Water saving: works with 4L or more of water.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick and easy to install: 2 access panels with theft prevention TORXsecurity screws.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 14kg.

Tootekood: DE-110300 ,   Tarneaeg: 14-21 päeva
1320,00 €

Wall-hung 700 S WC pan for disabled people
Ref. 110710

Wall-hung WC pan, 360 x 350 x 700mm.
Available with 700mm elongated pan for improved comfort for peoplewith reduced mobility (700 S).
Compatible with all standard frame systems available on the market.Elegant and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm.
Horizontal waste outlet: Ø 100mm.
Water saving: works with 4L or more of water.
Shrouded WC pan.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick and easy to install from the front thanks to a stainless steel mounting frame.
Supplied with fixing plate and 6 theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 14.5kg.

Tootekood: DE-110710 ,   Tarneaeg: 14-21 päeva
1512,00 €

Wall-hung BCN S WC pan
Ref. 110112

Wall-hung WC pan, 360 x 375 x 550mm.
Compatible with all standard frame systems available on the market.
Elegant and simple design.
Bacteriostatic 304 stainless steel.
Dual finish: bright polished pan interior and polished satin exterior.
Stainless steel thickness: 1.5mm.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm.
Horizontal waste outlet: Ø 100mm.
Water saving: works with 4L or more of water.
Shrouded pan.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick and easy to install from the front thanks to a stainless steel mounting frame.
Supplied with fixing plate and 6 theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
10-year warranty.

Weight: 12kg.

Tootekood: DE-110112 ,   Tarneaeg: 14-21 päeva
1422,00 €

Wall-hung BCN S WC pan
Ref. 110110

Wall-hung WC pan, 360 x 375 x 550mm.
Compatible with all standard frame systems available on the market.
Elegant and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.
Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm.
Horizontal waste outlet: Ø 100mm.
Water saving: works with 4L or more of water.
Shrouded pan.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steelblanking caps when installed without toilet seat lid.
Quick and easy to install from the front thanks to a stainless steelmounting frame.
Supplied with fixing plate and 6 theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 12kg.

Tootekood: DE-110110 ,   Tarneaeg: 14-21 päeva
1170,00 €

Wall-hung S21 S WC pan
Ref. 110310

Wall-hung WC pan, 360 x 350 x 535mm.
Compatible with all standard frame systems available on the market.
Elegant and simple design.
Bacteriostatic 304 stainless steel.
Polished satin finish.
Stainless steel thickness: 1.5mm.
One-piece pressed WC bowl, seam-free for easy maintenanceand better hygiene.
WC bowl surface is polished with rounded edges for easy cleaning.Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm.
Horizontal waste outlet: Ø 100mm.
Water saving: works with 4L or more of water.
Shrouded pan.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick and easy to install from the front thanks to a stainless steel mounting frame.
Supplied with fixing plate and 6 theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 11kg.

Tootekood: DE-110310 ,   Tarneaeg: 14-21 päeva
1260,00 €

Roostevaba terasest WC pott seinale Delabie S21 S must

Wall-hung S21 S WC pan

Ref. 110310BK

Wall-hung WC pan.
Compatible with all standard frame systems available on the market.
Elegant and simple design.
Bacteriostatic 304 stainless steel. Stainless steel thickness: 1.5mm.
Matte black Teflon® finish.
One-piece pressed WC bowl, seam-free for easy maintenance and better hygiene.
Concealed perimetral flushing rim.
Horizontal water inlet: Ø 55mm.
Horizontal waste outlet: Ø 100mm.
Water saving: works with 4L or more of water.
Shrouded pan.
Pre-drilled holes for fixing the toilet seat. Supplied with stainless steel blanking caps when installed without toilet seat lid.
Quick and easy to install from the front thanks to a stainless steel mounting frame.
Supplied with fixing plate and 6 theft prevention TORX security screws.
CE marked. Complies with European standard EN 997 for 4L flush.
Weight: 11kg.


TECHNICAL CHARACTERISTICS

Wall-hung S21 S WC pan

Ref. 110310BK
Height 350mm
Length 535mm
Width 360mm
Thickness 1.5mm
Finish Matte black 304 stainless steel
Tootekood: DE-110310BK ,   Tarneaeg: 14-21 päeva
1620,00 €
SLW 01NK

Tualettruumi loputusseade survevee jaoks, 24 V DC

OMADUSED

Tualettruumi loputusseadet veejaotusest pärineva survevee jaoks ei ole võimalik seda kasutada paagiga tualettruumi jaoks
süsteem reageerib kasutajate osavõtule anduri aktiivses vahemikus maksimaalselt 0,7 m kaugusel, minimaalne viibimisaeg aktiivses vahemikus on 7,5 s
vesi voolab pärast seda, kui kasutaja väljub aktiivsest vahemikust
reguleeritav loputusaeg 0,5 - 15,5 s
täiendava käsitsi loputamise võimalus nupu abil (nt puhastamise ajal)
automaatne hügieenipesu pärast iga 8 tualettruumi kasutamist ja pärast 24 tundi mittekasutamist
elektromagnetiline ventiil koos võimalusega reguleerida voolukiirust, võimalus tualetti loputada elektromagnetilise klapi mähise abil (nt elektrienergia katkestuse korral)
parameetrite reguleerimine puldiga SLD 03

SLW 01NK

Toilet flushing unit for pressured water, 24 V DC

CHARACTERISTICS

  • toilet flushing unit for a pressure water from water distribution, isn´t possible to use it for toilet with tank
  • system reacts to the user attendance in active range of the sensor at a maximum distance of 0,7 m, minimum stay time in active range is 7,5 s
  • water flows after the user leaves active range
  • adjustable flushing time 0,5 - 15,5 s
  • possibility of additional manual flush by push-button (f.e. during the cleaning)
  • automatic hygiene flush after each 8 use of toilet and after 24 hours non-use
  • electromagnetic valve with a possibility to regulate rate of flow, possibility to flush a toilet by turn of coil of the electromagnetic valve (f.e. in the case of electricity blackout)
  • parameters adjustment by remote control SLD 03




Tootekood: SAN-SLW 01NK, 24V ,   Tarneaeg: 14-21 päeva
546,00 €
