400 x 298 x 120 mm
ca. 500 paper towels / sensor with 500 ml soap bottle

• Combination consisting of a sensor liquid soap dispenser and a paper towel dispenser in robust, germ-reducing and easy-care stainless steel (AISI 304).
• All-stainless steel housing; all corners fully welded, visible surfaces satin finished and brushed.
  Further available surfaces: see below.
• Sensor liquid soap dispenser with EWAR® eModule touch-free operated soap pump.
• Designed for standard 500 ml disposable bottles of liquid soap or hand lotion.
• Paper towel dispenser with deep-drawn paper removal opening for easy paper removal.
• Designed for approx. 500 standard paper towels in zigzag fold. Paper size (folded): 240-250 mm x 100-115 mm.
• Inspection slots to indicate fill level.
• Accessible for refilling through lockable front flap with fall protection.
• Keyed alike cylinder lock in corrosion-resistant zinc die-casting.
• eModule battery-powered with two 1.5 V Baby/LR14 batteries.
  Power supply available as an option.
• Wear parts can be replaced as modules.
• Mounting: With four screws through key holes and one optional anti-theft hole in the back wall.
• Delivery includes fixing material, batteries, first fill with soap and one pack of paper towels.

• Weight (in kg): 4,8

Ø 40 x 220 x 40 mm
Stainless steel

• Panel mounted soap dispenser in robust, germ-reducing and easy-care stainless steel (AISI 316L).
• Solid stainless steel body; visible surfaces satin finished.
  Further available surfaces: see below.
• Projection: 80 mm
• One-hand operated and non-drip soap pump with pressure valve in stainless steel.
• Designed for standard liquid soaps.
• Refillable through decentralized soap container connected with suction tube.
• Wear parts can be replaced as modules.
• Installation dimensions: Ø 21-25 mm,
  panel thickness max. 40 mm.
• Mounting: With one counternut.
• Delivery includes fixing material and 1.5 m suction tube.

• Weight (in kg): 0,9

Inva tugitoru dushiliftiga 750x750x1200mm harjatud RST vasak

Inox Care Shower handrail,

with shower head rail central, left, 750 x 750 x 1200 mm, Stainless steel, shower head holder, colour dark grey (018)

• Inox Care as a robust and timeless classic with bacteriostatic properties
• Shower head holder with easy adjustment to any height and angle, self-adjusting clamp maintenance-free
• with long operating handle and multi-purpose side hook
• with Rose Gasket for sealing of the drilling points according to German standard DIN 18534-1
• with stainless steel roses Ø 70mm for concealed screw fixing
• In case of lightweight partition walls a backfill made of min. 20mm hardwood is needed
• produced in accordance with Regulation (EU) 2017/745 on medical devices
• CE-certified
• meets the requirements of German standard DIN 18040 and Austrian standard ÖNORM B 1600
• supplied with stainless steel Torx screw sØ 6 x 70 mm and plugs

• Product category : Shower handrail
• Product version : with shower head rail central
• Product group : 5500
• Axle dimension a1 : 750 mm
• Axle dimension a2 : 750 mm
• Axle dimension a3 : 1200 mm
• Diameter : 32 mm
• Fixing points : 4 St.
• Fixing type : rosettes mounting
• Additional colour : shower head holder, colour dark grey (018)
• Material : stainless steel, material No. 1.4301 (A2, AISI 304)
• Material addition : Shower head holder made of polyamide
• Surface : brushed finish
• Version : left
• Colour : Stainless steel
• Loading : max. 175 kg

Haceka Aspen tualettpaberihoidel matt must
