Veiser veetrapp 6004512 kõige madalam trapp1.png Zoom

Vieser One 6004512 Horisontaaltrapp EXTRA madal 50 1x32 1.2L/sek

Tootekood: AKV6004512
Kaubamärk:
Ühik: tk
Tarneaeg: 3-7 päeva
Hind:
45,75 €
Kogus: - +

Vieser One 6004512 Horisontaaltrapp EXTRA madal 50 1x32 1.2L/sek



Vieser One horizontal drain DN50 1x32 extra low



HVAC No. 3317307


The lowest floor drain on the market 69 mm

The Vieser One horizontal extra low floor drain is the lowest floor drain on the market, with a flow rate of 1.2 l/s The low structure is a significant benefit in both renovations and new construction.

Thanks to the efficient flow rate, the drain is suitable for use in both showers and bathtubs, and it is compatible with all Vieser drain covers and extension rings. The drain has one 32 mm side inlet.

Water trap based on membrane technology

The water trap is based on innovative membrane technology. The traditional water space is replaced with an airtight membrane water trap that opens as the water flows and closes when it stops, preventing sewer gases from entering the room.

The membrane water trap, made from silicone rubber, has a long life and functions reliably in different temperatures and conditions.

Hygienic and quiet

The membrane water trap of the extra low drain is very hygienic, as it does not collect impurities. Dirt is swept away with the water flow. If necessary, the water trap can be removed and lifted up.

The waterless membrane trap is silent in use. It is also an excellent option for spaces that experience problems with the water trap drying out.

The Vieser One floor drain is compatible with Vieser’s traditional gratings and Vieser’s design covers:



The package includes the drain, water trap, casting shield, clamping ring and a tool for installing the clamping ring.

Technical specifications

Vieser No.
6004512
HVAC No.
3317307
EAN
6430066742325
Package (box/pallet)
10/120
Package dimensions
35 x 25 x 70 cm
Package weight
0,5 kg
Material
Polypropylene PP
Usage
Suitable for regular residential wastewater sewage systems in accordance with the Finnish Ministry of the Environment’s decree on buildings’ water and sewer systems.
Flow
1,2 l/s
General information

The floor drain is compatible with Vieser extension rings, distance rings, membrane flange and gratings/covers. The drain has one 32 mm side inlet. The package includes the drain, water trap, casting shield, clamping ring and a tool for installing the clamping ring.






Video
